Rail Bender Category

Hydraulic Rail Bender

Hydraulic bend machine is a  a manual hydraulic special tool suitable for horizontally straightening or bending the rails on track.

Model: KWPY–600

             KWPY–400

             KWPY–300

Manual Rail Bender

Manual rail bender can straighten and bend light steel rails in horizontal level.

Advantage:it can straighten or bend rail in one time.

Applicable rails: 8-30kgs/m rails

1. Hydraulic Bend Machine Introduction

Hydraulic Rail Bender is used to on the rail under 50 kg/m and vertical curved track.
Advantages: saving power, a person can complete the curved or straight rail track action, unloading fast, you can quickly get a lot of bends. Disadvantages: cylinder portion wearing high maintenance costs; only take relatively small curvature bend below 150 ° bend, you need several minutes to complete. Suited to take round bends and curved corners.
Hydraulic Rail Bender is a railroad and a common railway maintenance equipment, you can get straight rails bend as needed, you can also get straight rails bend.

Rail Bender Model: KWPY-300

KWPY-300 Hydraulic Bender (Hydraulic Bender) (Hydraulic Rail Bender) - Used for horizontal bending of rails under 24kg/m with a minimum bending radius of 7M.

Rail Bender Model: KWPY-400

KWPY-400 Hydraulic Bender (Hydraulic Bender) (Hydraulic Rail Bender) - Used for horizontal bending of 30kg/m rails.

Rail Bender Model: KWPY-600

KWPY-600 Hydraulic Bender (Hydraulic Bender) (Hydraulic Rail Bender) - Used for horizontal bending of 30kg/m-50kg/m rails.

It is divided into horizontal hydraulic rail bender (hydraulic rail bender) and vertical hydraulic rail bender (hydraulic rail bender) according to the direction of rail bending.

Rail Bender Model: KWPY-III

KWPY-III hydraulic straight (bending) rail machine is used for horizontal bending of rails below 24 kg/m with a minimum bending radius of 5 M.

2. Hand-operated Rail Bending Tool

Manual Rail Bender Usuage

Manual rail bender can straighten and bend light steel rails in horizontal level. .

Manual Rail Bender Disadvantage

It needs big force, needs 2 to 3 person to operate it.

Manual Rail Bender Advantage

It can straighten or bend rail in one time.

Manual Rail Bender Applicable Rails

Straighten or bend rails of 8kg/m,12kg/m,15kg/m,18kg/m, 22kg/m,24kg/m,30kg/m

Advantages.1

Our companies to actively participate in railway and mining construction for more than 30 years. For the domestic railway, coal mines, subway,ports, such as steel rail transport to open in the field of equipment shortages, roads, offers a wide range of materials.

Advantages.2

In order to strictly control the quality of each product and ensure that all our railway and mining equipment meet international standards and our customers' expectations, our advanced manufacturing equipment includes the following: Vertical milling machining center ,Numerical control lathe, Numerical control cutting,and all kinds of equipment more than ten hundreds .
