DN250 PN16 CF8 задвижка для
DN250 PN16 CF8 задвижка для

DN250 PN16 CF8 задвижка для


Поделиться:


Цена:3 825,51 ₽ - 765 102,00 ₽*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Aug-20-2025 4858.60 $* 4955.33 $*
Jul-20-2025 3940.87 $* 4019.39 $*
Jun-20-2025 4781.77 $* 4877.91 $*
May-20-2025 4743.10 $* 4838.14 $*
Apr-20-2025 3787.68 $* 3863.91 $*
Mar-20-2025 4667.62 $* 4760.77 $*
Feb-20-2025 4628.73 $* 4721.44 $*
Jan-20-2025 4590.71 $* 4682.15 $*

Характеристики

Product Description

CHINA valve DN80 3inch 150LB 300LB Class Standard Stainless Steel CF8 rising stem Manual Hand Wheel running flanged Globe Valve

Cast Steel Globe Valve
Design Standard
BS1873 ,ASME B16.34
Pressure Rating
ASTM B16.34
Temperature Rating
ASTM B16.34
Face to Face
ASME B16.10
Flange Ends
ASME B16.5,ASME B16.47
Buttwelding Ends
ASME B16.25
Inspection&Test
API598
Size Rating
2"-48"

Advantages of Globe valves

>> Good shutoff capability
>> Moderate to good throttling capability
>> Shorter stroke (compared to a gate valve)
>> Available in tee, wye and angle patterns,
each offering unique capabilities
>> Easy to machine or resurface the seats
>> With disc not attached to the stem, valve
can be used as a stop-check valve

Detailed Images

Globe valves usually have rising stems, and the larger sizes are of the outside screw-and-yoke construction. Components of the Globe valve are similar to those of the gate valve. This type of valve has seats in a plane parallel or inclined to the line of flow.

Part Name
Carbon Steel
Stainless Steel
Alloy Steel
Body
ASTM A216 GR WCB
ASTM A351 GR CF8
ASTM A217 GR WC6
Seat
ASTM A105
_
ASTM A182 GR F304
Disk
ASTM A216 GR WCB
ASTM A351 GR CF8
ASTM A217 GR WC6
Stem
ASTM A276 Type 410
ASTM A276 Type 304
ASTM A182 GR WC6
Stud
ASTM A193 GR B7
ASTM S193 GR B8
ASTM A193 GR B16
Nut
ASTM A194 GR 2H
ASTM A194 GR 8
ASTM A194 GR 4
Back Seat
ASTM A182 GR F6a
ASTM A182 GR F304
ASTM A182 GR F304
Gasket
Graphite+SS304
Packing
Graphite
Pin
ASTM A194 GR 2H
ASTM A276 Type 304
ASTM A276 Type 410
Packing Bushing
ASTM A182 GR F6a
ASTM A182 GR F304
ASTM A182 GR F304
Eyebolt
ASTM A193 GR B7
ASTM A193 GR B8
ASTM A193 GR B16
Eyebolt Nut
ASTM A194 GR 2H
ASTM A194 GR 8
ASTM A193 GR 4
Gland
ASTM A216 GR WCB
ASTM A351 GR CF8
ASTM A216 GR WCB
Bonnet
ASTM A216 GR WCB
ASTM A351 GR CF8
ASTM A216 GR WCB
Stem Nut
ASTM B148
UNS C95200
ASTM B148
UNS C95200
ASTM B148
UNS C95200
Handwheel
ASTM A197
ASTM A197
ASTM A197
Handwheel Nut
ASTM A108 GR 1020
ASTM A182 GR F304
ASTM A108 GR 1020
