Изоляция под заказ высокотемпературная Керамическая волоконная плита

Описание и отзывы

Трекер стоимости

Характеристики

Quick  details



application	Heat insulation	Lengths	600/900/1000mm
width	300/600/1000mmm	Chemical composition	Al2o3+sio2
grade	High aluminum	Working temperature	1000/1050/1100/1200/1350
Product name	Ceramic fiber board	Place of origin	Zibo china (mainland)
Thickness	10-50mm	Brand name	Minye
Item	Thermal insulation ceramic fiber pipe	size	600*300*150-300
Density	260-320	color	White
Package	pallet	Classification temperature	1050/1260/1360/1430







Item/specifications	Common	Standard	High-purity	High aluminum	Containing zirconium
Classification temperature	1050	1260	1260	1360	1430
Working temperature	≤1000	1050	1100	1200	1350
Color	white	white	white	white	white
Bulk density (kg/m3)	260-320	260-320	260-320	260-320	260-320
Permanent linear shrinkage(24h bulk bensity 320kg/m3)	-4(1000℃)	-3(1000℃)	-3(1000℃)	-3(1000℃)	-3(1000℃)
Thermal conductivity(w/m.k) Bulk density285kg/m3	0.085(400℃) 0.132(800℃) 0.180(1000℃)	0.085(400℃) 0.132(800℃) 0.180(1000℃)	0.085(400℃) 0.132(800℃) 0.180(1000℃)	0.085(400℃) 0.132(800℃) 0.180(1000℃)	0.085(400℃) 0.132(800℃) 0.180(1000℃)
Al2o3	42%-44%	45%-46%	47%-49%	52%-55%	39%-40%
Regular size(mm)	600*400*10-50       900*600*20-50



All kinds of ceramic fibre board adopt ceramic fibre which is in Corresponding temperature level as raw material, through the large automatic vacuum filter molding machine to shape them, then they will be done after special baking.
The product with good toughness and strength appears flattening and the ceramic material distributes uniformity, it also has excellent Thermal insulation performance
Heating is not inflated, light, construction convenient, free shear and bending, is the ideal energy-efficient insulation materials of a furnace, piping and other equipment

Shandong Minye Heat-Preservation Material Co., Ltd is an innovative modern enterprise specializing in aluminum silicate equipment. Companies adhering to the "integrity, innovation, professionalism, quality" business philosophy, research and development of the production of acupuncture blanket production line technology, quality, safety and energy, for six consecutive years of national sales, the majority of customers praise and praise, in the industry Established a good reputation and excellent market position.
