1080p 6ch Мобильный DVR JF-S6 диктофон Blackbox в сочетании с BPC автоматические пассажирские счетчик 2 камерами Wi-Fi

New Auto Video People Counter with MV06 Mobile DVR

Overview

• What’s Bus Passenger Counter

Bus Passenger Counter (BPC) is a smart compact device backedby stereoscopic distinguish technology same as KINEC.It is designed for countingpeople cross doors of buses, trains andother entrances.

The video counter works with binocular cameras, which can offer the most accurate counting in the vehicle from morning to evening.

 New Counter Specifications

1. High precision counting accuracy (>97%)


2. Popular Hi3520D chips solution


3. Rich RS-232 for external devices


4. 4CH Video Input, 2CH Video Output


5. Really Vandal-proof & EMC for buses


6. Excellent power protection 9-36V,10A max


7. Effectively distinguish bidirectional moving, shoulders, retention, wandering, luggage, etc


8. Well-tested design in thousands of buses over the world


9. 195-300cm (height), 80-300cm(width)


10. Easy setup and connection to IPAS system


11. 300,000pcs of records saved in memory


12. Smartly Resent records when network is lost


13. 30-90MB data plans only every month


14. Used in step environment


15. Built-in 3G/WIFI/GPS optional


16. Max 4 bus doors with combination of counters

• How Counter Works?

BPC will detect and analysis the height, shape, direction of moving objects when somebody crosses the field of surveillance. The counter will generate a piece of record to show IN or OUT result. According to visual parallax theory, counter can compute image position deviationto obtain object 3D geometrical information. To combine two CCD chipsto observe the differences between each other.

Package and Delivery

Package: Well packed inside gift box.
