* Audible and visual alarm for Occlusion,Equipment failure,Software Exception,operation, Software Exception, Injection finish,Limited finished,Battery running out,Improperly installed,Abnormal operation etc.
* Preset Solution Volume to greatly reduce the workload of nurses.
* Three Work modes:Rate mode,Time Volume mode,Dosage Weight mode.
*One-key operation makes setup easy and simple.
*Syringe Plunger Grabble Detector,operable with one hand in a No-Germ Environment.
* Automatically record the settings of last injection; Sun-500z can store 2000pcs of injection records and it has a drug library.HD LCD Display,high capacity wors,friendly user interface,dynamically dispiay working status.
*Freely Stackble:Freely stack one onto another to provide multiple Solutions,which have a wide range of clinical applications.
* OEM is available.
Specs
Injection Rate
50(60)ml Syring 0.1ml/h----1500ml/h(0.1ml/h step)
30ml Syring 0.1ml/h----900ml/h(0.1ml/h step)
20ml Syring 0.1ml/h----600ml/h(0.1ml/h step)
10ml Syring 0.1ml/h----300ml/h(0.1ml/h step)
Rate Accuracy
Within + 3%(after correct calibration)
Mechanical
Within + 2%
Maximum Stackable
8pcs
Purge Rate
50(60)ml Syring: 1500ml/h
30ml Syring: 900ml/h
20ml Syring: 600ml/h
10ml Syring: 300ml/h
Bolus Rate
50(60)ml Syring: 1200ml/h
30ml Syring: 720ml/h
20ml Syring: 480ml/h
10ml Syring: 240ml/h
Volume Limit
0.1ml ---- 9999.9ml(0.1ml step)
Total Injection Volume
0.1ml ---- 9999.9ml(0.1ml step)
Occlusion
High 800mmHg+ 200mmHg(106.7kPa+26.7kPa)
Medium 500mmHg+ 100mmHg(66.7kPa+13.3kPa)
Low 300mmHg+ 100mmHg(40.7kPa+13.3kPa)
Power Source
100---240V 50/60Hz; Internal rechargeable Li-battery, DC 12V
KVO Speed
0.1ml/h ---5ml/h (0.1ml/h step)
Power Consumption
35VA
Syringe
Compatible with 10ml,20ml,30ml,50/60ml syring of any brands after correct calibration
