Настенный скрытый резервуар для унитаза 8801-13-1 в стене Встраиваемый Клапан резервуара

Application Purpose

Characteristics

Ordering information

Product Details

·For installation in split-height preWall construction in front of a solid or drywall construction .

· For a floor construction 80mm-200mm .

·For wall-hung WC with fastening distance 180mm or 230mm .

· Frame height 1140 mm

· Adjustable flush volume

· Top  water supply connection .

· Self-supporting frame .

·Cistern heat preservation ,anti-condensation protection .

· Powder-coated ,color Hansbo blue .

·Galvanized leg supports , adjustable 0-200mm .

· 1/2” x 3/8”Water supply angle valve .

· Flush outlet bend ,φ90/110 or HDPE φ 90/110,options .

·Flush connect pipe , φ45,standard length 180mm , can order 250mmlength .

· Flush outlet pipe , φ90,standard length 180mm , can order 250mmlength .

· Flush connect pipe rubber ,flush outlet pipe rubber .

·Maintain window protect frame , ABS material,can be cut according to the actually height .

· Protection plug .

· 2group rods M12 for ceramics fastening .

· 6group setscrew .

·Maximum flush can adjustable between 6L/7.5L .

·Maximum flush can adjustable between 3L/4L .

·Factory flush setting 3L/6L
