Ys-Zf1500 удобная установка компьютеризированная машина для ротогравировки пластика среднего
- Категория: Rotogravure Printing Machines >>>
- Поставщик: Ruian,Benyue,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.41 $* | 0.80 $* |
| Aug-19-2025 | 0.38 $* | 0.67 $* |
| Jul-19-2025 | 0.25 $* | 0.52 $* |
| Jun-19-2025 | 0.31 $* | 0.31 $* |
| May-19-2025 | 0.85 $* | 0.66 $* |
| Apr-19-2025 | 0.3 $* | 0.36 $* |
| Mar-19-2025 | 0.0 $* | 0.30 $* |
| Feb-19-2025 | 0.6 $* | 0.46 $* |
| Jan-19-2025 | 0.51 $* | 0.33 $* |
Характеристики
Products Description
The machine is suitable for glassine paper, BOPP, PET,PVC,PE,NYLON,aluminum foil and paper etc with roll type multicolor
continuous printing, it is widely used for high quality printing production.
main parameterThe machine is suitable for glassine paper, BOPP, PET,PVC,PE,NYLON,aluminum foil and paper etc with roll type multicolor
continuous printing, it is widely used for high quality printing production.
main parameter
continuous printing, it is widely used for high quality printing production.
main parameterThe machine is suitable for glassine paper, BOPP, PET,PVC,PE,NYLON,aluminum foil and paper etc with roll type multicolor
continuous printing, it is widely used for high quality printing production.
main parameter
machine spec.
1 Overall machine is permutation combined type
2 shaftless pneumatic cone plate, for exchanging save time and convenient
3 static balance aluminum alloy guide roller, sealing type oven, Energy conservation and fast drying, auto-consent temperature
control system
4 unwinding, feeding traction adopt fully automatic tension controller and magnetic powder brake control
5 rewinding, discharging traction adopt vector inverter control, running is more steady
6 pneumatic back press type movable doctor blade
7 ink cycle system, expand air shaft type unload and load shaft
8 high precision gear drive box, adopt proprietary technology
9 rewinding , unwinding is rotation double station frame, to realize no-stop splicing system
10 fully automatic computer registration device, can choose static inspecting menumachine spec.
1 Overall machine is permutation combined type
2 shaftless pneumatic cone plate, for exchanging save time and convenient
3 static balance aluminum alloy guide roller, sealing type oven, Energy conservation and fast drying, auto-consent temperature
control system
4 unwinding, feeding traction adopt fully automatic tension controller and magnetic powder brake control
5 rewinding, discharging traction adopt vector inverter control, running is more steady
6 pneumatic back press type movable doctor blade
7 ink cycle system, expand air shaft type unload and load shaft
8 high precision gear drive box, adopt proprietary technology
9 rewinding , unwinding is rotation double station frame, to realize no-stop splicing system
10 fully automatic computer registration device, can choose static inspecting menu
1 Overall machine is permutation combined type
2 shaftless pneumatic cone plate, for exchanging save time and convenient
3 static balance aluminum alloy guide roller, sealing type oven, Energy conservation and fast drying, auto-consent temperature
control system
4 unwinding, feeding traction adopt fully automatic tension controller and magnetic powder brake control
5 rewinding, discharging traction adopt vector inverter control, running is more steady
6 pneumatic back press type movable doctor blade
7 ink cycle system, expand air shaft type unload and load shaft
8 high precision gear drive box, adopt proprietary technology
9 rewinding , unwinding is rotation double station frame, to realize no-stop splicing system
10 fully automatic computer registration device, can choose static inspecting menumachine spec.
1 Overall machine is permutation combined type
2 shaftless pneumatic cone plate, for exchanging save time and convenient
3 static balance aluminum alloy guide roller, sealing type oven, Energy conservation and fast drying, auto-consent temperature
control system
4 unwinding, feeding traction adopt fully automatic tension controller and magnetic powder brake control
5 rewinding, discharging traction adopt vector inverter control, running is more steady
6 pneumatic back press type movable doctor blade
7 ink cycle system, expand air shaft type unload and load shaft
8 high precision gear drive box, adopt proprietary technology
9 rewinding , unwinding is rotation double station frame, to realize no-stop splicing system
10 fully automatic computer registration device, can choose static inspecting menu
type | YS-Z800 | YS-Z1100 |
Printing width | 800mm | 1100mm |
Roll width | 820mm | 1120mm |
Color units | 7color 9units | 7color 9units |
Rewinding and unwinding diameter | 600mm | 600mm |
Printing plate diameter | 100-270mm | 100-270mm |
Paper core inner dia. | φ76mm | φ76mm |
registration precision | ±0.18mm | ±0.18mm |
Printing speed | 50-100m/min | 50-100m/min |
Machine speed | 120m/min | 120m/min |
Oven heating power | 68kw | 82kw |
Total power | 80kw | 100kw |
overall machine weight | Approx 10000kg | Approx 12000kg |
dimension | 1200*2050*2600mm | 1200*2250*2700mm |
