Лидер продаж Китай Высококачественная эпоксидная ткань

Лидер продаж Китай Высококачественная эпоксидная ткань

Категория: Coating Machines >>>
Поставщик: Ruian,Benyue,Machinery,Co.,Ltd.

Цена:*

Количество:

Описание и отзывы

Трекер стоимости

Месяц	Минимальная цена	Макс. стоимость
Sep-19-2025	0.47 $*	0.94 $*
Aug-19-2025	0.31 $*	0.28 $*
Jul-19-2025	0.55 $*	0.80 $*
Jun-19-2025	0.65 $*	0.31 $*
May-19-2025	0.16 $*	0.33 $*
Apr-19-2025	0.39 $*	0.72 $*
Mar-19-2025	0.94 $*	0.43 $*
Feb-19-2025	0.36 $*	0.46 $*
Jan-19-2025	0.73 $*	0.6 $*

Характеристики

Products Description

Features:
1 overall machine adopt 4frequency motor control, overall machine tension automatic control, speed keep synchronous
2 independent unwinding frame, adopt magnetic powder auto control the tension
3 gravure coating method, coating doctor blade shaft adopt heavy double shaft machine independent moving, blade adjust by manual
with pneumatic, angle adjust freely, coating quantity depend the mesh of gravure roller, different coating quantity can change
different mesh gravure roller.
4 oven 10m for 4section independently control, hot air intake drying system, adjustable inner cycle air intake and out device, air
intake and out with strong air , dry thoroughly
5 oven inner guide wheel is active synchronous with the mainframe, drive adopt synchronous belt drive guide wheel to assure
synchronous to reduce material stretch and deformation, cylinder pneumatic open oven and film pass operation panel so that worker
can work very easily.
6 the tension between coaitng roller and traction steel roller adopt float swing arm by PLC auto-control
7 auto-length and speed meter device
8 webguide adopt EPC air sensitive register to assure the trimness when rewinding
9 rewinding and unwinding adopt key type airshaft for easily operate when loading and unloading the material, air shaft take
in/off adopt safety lock type
10 high presicion up press traction device, steel roller cooling adopt water cycle to make the film surface more smooth and neat.
to reach good cooling effect.

MAIN PARAMETER

Type	TB-C1000
Coating method	Gravure coating
Coating width	1000mm
Unwinding dia.	Ø600mm
Rewinding dia.	Ø620mm
Oven length	10M
Oven temperature	5-120°C
Work speed	10-80m/min
Machine speed	100m/min
Diamension	10000×2800×3500mm
Machine weight	12000kg
Overall machine total power	85kw
