Весы стекловолокна EC-135 800 Размер RC вертолет

Описание и отзывы

Трекер стоимости

Характеристики

Scale fiberglass Airwolf 800 size RC Helicopter Fuselage



Including magnetic cabin lock system, for quick access. Transparent front window, side windows open for heat dissipation. Including weaponry parts, mounting accessories and landing gear. Landing gear is not retracteable, all mechanical components are included.



Accessory:

*Fiber Glass scale fuselage

*Horizontal stabilizer

*Langing Gear Set

*Screw pack





Body length:	1765mm
Length incl. rotors:	1960mm
Width:	355mm
Height:	510mm
Main rotor diameter	1660mm
Main blade length:	750mm
Fenstron diameter:	160mm
Tail blade length:	70mm
Main shaft diameter:	12mm
Tail shaft diameter:	5mm
Spindle diameter:	8mm
Main blade count:	2
Tail blade count:	9
Drive gear ratio:	1:13.8:4.7
Motor:*	1x 750MX 450KV brushless outrunner , 12S capable
Speed controller:*	1x 120A brushless, 12S capable
Servo:*	3x metal gear cyclic, 1x metal gear tail servo
Battery:*	44.4V 5000mAh 35C
Flight time:	5 minutes
Takeoff weight:	8000g
Flight Stabilization:*	3 axis flybarless gyro
Radio Control:*	min. 6 channel with pitch and throttle curves
