390HP JMC 6X4 Construction Mine Tipper/Dump Truck with parts

Product Description

The basic information
Announcement model :	SXQ3250J4A3D5A
Driving mode:	6X4
Wheelbase:	1800+4200+1350mm,1800+4600+1350mm 1800+3800+1350mm
Body length:	10.825 m,11.7 m,11.375 m
Width:	2.496 m
Height:	3.45 m
Wheelbase:	front wheelbase: 2022/2022mm;Rear wheelbase: 1830/1830mm
Vehicle weight	15.45 tons,11.11 tons
Rated load:	15.42 tons
Total mass:	31 tons , 43 tons
Tonnage level:	heavy truck
Approach Angle:	19 degrees,16 degrees
Departure Angle:	22 degrees , 19 degrees , 24 degrees , 25 degrees , 15 degrees
Origin:	jinan, shandong
The engine
Engines:	d10.38-40
Cylinder number:	6
Fuel types:	diesel
Capacity:	9.726 L
Emission standards:	country 4 / Europe 4, country 5 / Europe 5
Maximum horsepower:	390 HP,340 HP,310 HP
Maximum output power:	276kW,249kW,228kW
Torque:	1560N·m,1490N·m,1390N·m
Maximum torque speed:	1200-1500rpm
Rated speed:	2000rpm,1900rpm
Engine type:	straight six cylinder, water - cooled, four stroke, supercharged medium - cooled, high - pressure common rail
Packing case parameters
Container length:	7.8m,8.2m
Container width:	2.3m
Container height:	1m,1.07m
Container type:	back dump type
TRANSMISSION
Transmission:	12JSD200T
Forward gear:	12,10
Number of reversals:	2
TIRE
Tire specification:	11.00-20,11.00R20,12.00-20 18PR,12.00R20 18PR
Number of tires:	12
The fuel tank
Fuel tank capacity:	400L
chassis
Description of rear bridge:	AC16 bridge
Allowable load of rear axle:	16000kg,17500kg
Rear axle speed ratios:	4.77,4.42,5.45
