Asterisk Analog card TDM800PL PCI-E 8 FXO/FXS 2U compatible with DIGIUM







PCI-E asterisk card is a new generation analog card with interchangeable FXS
and FXO modules. It
can eliminate the requirement for separate channel banks or access gateways.

* PCI-E card is upgraded board, the voice is clearer than previous card quality,
lower noise, more
flexible Configuration, and more reliable.
* High security: It adopts tertiary thunder preventing technology, can prevent the
thunder and
lightning from striking effectively.
* No additional power connector or supplier is required for the operation of FXS
modules, reduced the
line wave of the power, has improved the voice quality.
* World Wide Usable: Configurable line interface to meet global telephone line
interface requirements.
* User could choose any of combinations of FXO_100 FXS_100,FXO_200, FXS_200
modules
according to customer’s requirements.
* 32 bit bus master DMA data exchanges across PCI interface at 132Mbytes/sec for
minimum host
processor intervention.
* The high stability firmware is exported / imported with DMA data exchange, so it is
accelerated and
reduced CPU load greatly. Under the environment of the same hardware, CPU rate of
utilization is equal to CPU rate of utilization of using 4-24 port analog card.

* It supports all the functions of Asterisk PBX systems needed.
* Humanization is designed: The module socket that should be nipped is all adopted
and stuck to one
slice of sockets, can prevent stabing users finger effectively.
* For 4U chassis.



New function:
* Easy to install , using way is same as DIGIUM Asterisk card
* If use Trixbox/Elastix/Freeiris2 IPPBX software, it can automatic recognition our
cards, don’t need to
install any drivers.



Product Features
Compatible with digium's newest model:TE420, TE412P.
Using the same driver as Digium: wct4xxp.ko
High performance due to the support of interrupt latency(at most 127ms).
Supporting EC Module with Octasic EC chip.
Supporting Hardware HDLC and channel switching.
Specifically designed for the Asterisk platform, available for Freeswitch, Yate and
other
open source projects.



OS

and opensources IP-PBX supported
Os:unix,linux and Solaris
Open source PBX system:Asterisk,Trixbox,elastix,yate,freeswitch,callweaver and
more



Environment
Temperature :0°C – 50°C(operation),-20°C - 65°C(storage)
Humidity:8% - 90% ( non-condensing )



Leds
Total leds: 4.
One tri-colors led for every interface.
