Высокое качество 4CH 1080P sd карта mdvr 3g gps с 4G WiFi


Поделиться:


Цена:*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-16-2025 0.39 $* 0.16 $*
Aug-16-2025 0.44 $* 0.1 $*
Jul-16-2025 0.39 $* 0.33 $*
Jun-16-2025 0.69 $* 0.28 $*
May-16-2025 0.23 $* 0.4 $*
Apr-16-2025 0.80 $* 0.51 $*
Mar-16-2025 0.63 $* 0.78 $*
Feb-16-2025 0.11 $* 0.58 $*
Jan-16-2025 0.22 $* 0.66 $*

Характеристики



Product Description





High Quality 4 channel 1080P dual SD card mobile dvr with GPS 4G WiFi






Features:


Ÿ Built-in high performance Hisilicon chipsets, coded with H.264/H.265 standard, high compression rate and image quality


Ÿ AHD/TVI/CVI/IPC/ANALOG five in one video input, wide compliance


Ÿ 4+1 live preview and storage


Ÿ 1CH synchronized AV output, 1CH VGA output


Ÿ Support UPS power input


Ÿ Built-in G-sensor, monitor the driving habits


Ÿ Reverse Assistance


Ÿ Adjust the camera image horizontally and vertically


Ÿ Adjust the camera image 90 degrees





Power:


Ÿ Professional In-Vehicle power design, 8-36V DC Wide Voltage Range


Ÿ Multiple protection circuits like under-voltage, short, reversed plug-in


Ÿ Smart power management system, shutdown under low voltage, low consumption when standby


Ÿ Report the GPS info to the server regularly with very low power consumption, compliant with JT/T794-2011 standard


Data Storage:


Ÿ Built-in super capacitor to avoid data loss and disk damage caused by sudden outage


Ÿ Special file management system to encrypt and protect the data


Ÿ Proprietary technology to detect the bad track of the disk which can make sure the continuity of video and long service life of the disk


Ÿ Support dual SD card storage, maximum 2 x 256GB


Transmission Interface:


Ÿ Support GPS/BD/GLONASS optional, high sensitivity, fast positioning


Ÿ Support wireless download by WiFi, 802.11b/g/n, 2.4GHz


Ÿ Support 3G/4G transmission, LTE/HSUPA/HSDPA/WCDMA/EVDO/TD-SCDMA





sd card 4ch mdvr 3g gpssd card 4ch mdvr 3g gps





 sd card 4ch mdvr 3g gps


CMS Software and mobile APP fleet management


sd card 4ch mdvr 3g gps




Office and Workshopsd card 4ch mdvr 3g gps





Product Detail



















































































































Technical Parameter:



Item



Device Parameter



Performance



System



Main Processor






Hi320d v400



Operating System



Embedded Linux OS



Operating Language



Chinese/English/Russian



Operating Interface



GUI, Support mouse and remote control



Password Security



Two Layer password Admin/User



Audio


&


Video






Video Standard



PAL/NTSC



Video compression



H.264/H264+/H265/H265+



 Image resolution



1080P/720P/960H/D1/CIF



Playback Quality



1080P/720P/960H/D1/CIF



Compound mode



A variety of ways



Decoding ability



4ch 1080P



Recording quality



Class 1-6 optional



Image display



Single/QUAD display optional



Firmware upgrading



Upgrading mode



Manual/Automatical/Remote/Emergency Recovery



Upgrading method



USB disk/Wireless network/SD card



Function Extension



GPS/BD/GLONASS



Support detecting antenna Plug in/Unplug/Short circuit



2G/3G/4G



Supports CDMA/EVDO/GPRS/WCDMA/FDD LTE/TDD LTE



WIFI



802.11b/g/n, 2.4GHz



Others



Power input



8V~36V DC



Power output



5V 300mA



Power consumption



Standby 8.5mA


Maximum consumption 18W @12V 1.5A @24V 0.75A



Working temperature



-20 --- 70



Storage Size



1080P  1G/h/channel


720P   0.5G/h/channel


960H   0.38G/h/channel



Dimension



142*153*33mm

















Certifications






OUR CERTIFICATES







sd card 4ch mdvr 3g gps







Company Information





sd card 4ch mdvr 3g gps

about us


Eastyle Electronics was built in 2008, which is a manufacturer of Vehicle electronics products with well-equipped testing facilities and strong technical force.
With a wide range, good quality, reasonable prices and stylish designs, our products are extensively used in all kinds of vehicles like bus, truck, car, taxi, trailer, tanker...etc.











Contact Us









sd card 4ch mdvr 3g gps











Packaging & Shipping




PACKAGE:


Standard export carton packing.


DELIVERY TIME:


3-20 days after confirming order,detail delivery date should be decided according to
production season and order quantity.



sd card 4ch mdvr 3g gps





FAQ





FAQs





Q1. What is your terms of packing?


A: Generally, we pack our goods in neutral white boxes and brown cartons. If you have legally registered patent,


we can pack the goods in your branded boxes after getting your authorization letters.




Q4. How about your delivery time?





A: Sample order: 2-3 days


 100 kits order: 2 weeks


 1000 kits order: 4 weeks




Can you provide technical support


Yes, we can provide professional technical support before and after sales






Q2. What is your terms of payment?





A: T/T , PayPal, Western Union.




Q5. Do you test all your goods before delivery?





A: Yes, we have 100% test before delivery




Can you arrange shipment for us?


Yes, we have cooperative Forwarder agent, can make sure goods will be delivered fast, safe at reasonable costs.






Q3. What is your terms of delivery?





A: EXW, FOB, CIF, DDU.




Q6: How do you make our business long-term and good relationship?





A:1. We keep good quality and competitive price to ensure our customers benefit ;


2. We respect every customer as our friend and we sincerely do business and make friends with them,


no matter where they come from.
