От известного китайского бренда DW-100 песок Землеройная техника корабль
- Категория: Земснаряд >>>
- Поставщик: Xuzhou,Shangheng,Engineering,Machinery,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.71 $* | 0.68 $* |
| Aug-16-2025 | 0.47 $* | 0.86 $* |
| Jul-16-2025 | 0.67 $* | 0.83 $* |
| Jun-16-2025 | 0.5 $* | 0.43 $* |
| May-16-2025 | 0.57 $* | 0.41 $* |
| Apr-16-2025 | 0.85 $* | 0.71 $* |
| Mar-16-2025 | 0.76 $* | 0.22 $* |
| Feb-16-2025 | 0.11 $* | 0.29 $* |
| Jan-16-2025 | 0.4 $* | 0.36 $* |
Характеристики
DW-100 Sand excavation equipment ship performance
Serial number | Indicator requirements | Specifications | Note |
| 1 | Total length | 20m | When the bridge is in a horizontal state |
| 2 | Hull length | 14m | |
| 3 | Type width | 5.8m | Single hull width 1.8m |
| 4 | Type depth | 1.6m | |
| 5 | Load Draught Depth | 0.80m | |
| 6 | Main Rack Size | 5mx2.5m | |
| 7 | Gantry High | 5m | |
| 8 | Dig deep | 3-10m | |
| 9 | Extracting items | Stone, sand | |
| 10 | Design processing capacity | 100-150m³/h | |
| 2.Main structure and specification of dw-100 dredging equipment | |||
| number | name | number | details |
| 1 | Floating body | 2 | The size of the floating body is 20* wide 1.8* high. The bottom plate of the floating body is 8mm and the side plate is 8mm. The side plate is 6mm |
| (decomposition) | |||
| 2 | Large arm for sand dredging and its appendages | 1 | Pole type big arm, specification 12*1.8*0.6m, bottom beam with 260mm square steel, surface beam with 220mm square steel, both sides with iron plate reinforcement, iron plate thickness of 8mm |
| 3 | scoop | 56 | Base plate thickness: 12mm wall plate thickness: 12mm bucket lip: manganese 13 cast steel gusset plate, wear-resistant, thickened; |
| 4 | Chain plate | High manganese steel casting, manganese content 13, more wear - resistant and durable. | |
| 5 | Dredging driving wheel | 1 | Adopt quadrangle wheel, diameter of driving wheel: 1.20m; plate: 20mm |
| Carbon steel plate making | |||
| Diameter of driving wheel shaft: 150mm | |||
| 6 | Sand-digging driven wheel | 1 | Adopt pentagonal wheel, diameter of driven wheel is 1.40m |
| Plate: 25mm carbon steel plate | |||
| Plate: 25mm carbon steel plate | |||
| 7 | Gravel belt | 1 | Length 8m conveying bandwidth 800mm |
| 8 | Drum screen | 1 | Length 2500 diameter 1200mm |
| 9 | Sand belt | 1 | 2500 diameter 1200 mm in Length |
| 10 | Waste chute | 1 | Length: 3m, width: 0.5m, height: 0.3m, thickness: 8mm |
| 11 | The water pump | 1 | Water flow 180m /h |
