Беспроводная система ушного монитора tr10 с истинным

           MAIN FEATURE

• Using UHF 630-660 MHz band to avert frequency interference.


• Eight audio source input jacket, support phantom power microphone input.


• One transmitter can use unlimited body-pack receivers.


• PLL circuit design, preset 99 non-interfered channels.


• Automatic frequency scan feature searches for available frequencies.


• Splendid LCD display, shows the RF level, AF level, channel and frequency.


• Strong transmitter power, the distance can be reached 100 meters.


• Half of 19 inch rack design, two systems can be connected for 19" rack.


• Designed for professional stage use.

          TRANSMITTER

• Power Supply:DC 15-17V


• Transmitter Power:100mW


• Modulation Type:FM


• Spurious Emission:>60dB


• Frequency Stabilization :±0.005%


• Deviation:40KHz


• Total Harmonic Distortion:< 0.5%


• Earphone Impedance:32 ohm

           RECEIVER (BODY-PACK)

• Power Supply:3V(2x1.5V AA battery)


• Total Harmonic Distortion:< 0.5%


• Signal/Noise Ratio:>90dB


• Image Rejection:>80dB


• Receiving Sensitivity:10dBuV (SINAD=30dB)


• De-Emphasis:50uS


• AF Output Power:100mW


• Earphone Impedance:32 ohm
