Высокопроизводительная неприлипающая пленка PTFE по низкой
- Категория: Пластиковая пленка >>>
- Поставщик: Taixing,Fleet,Hi-Tech,Material,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-17-2025 | 40.80 $* | 42.60 $* |
| Aug-17-2025 | 40.67 $* | 42.42 $* |
| Jul-17-2025 | 34.84 $* | 36.56 $* |
| Jun-17-2025 | 39.77 $* | 41.10 $* |
| May-17-2025 | 34.66 $* | 36.10 $* |
| Apr-17-2025 | 39.36 $* | 41.67 $* |
| Mar-17-2025 | 38.25 $* | 40.66 $* |
| Feb-17-2025 | 38.53 $* | 40.14 $* |
| Jan-17-2025 | 38.83 $* | 40.62 $* |
Характеристики
High performance low price non stick PTFE membrane film
Product information
PTFE Teflon Film has made extensive investments in the latest skiving technologies, enabling us to provide customers with high quality, competitively priced products. For its excellent dielectric capability, anti-aging and anti-corrosion property, super thin PTFE teflon skived Tape&Film has been used in a wide range of industries including the electronics and semi density industries.
Technical Datasheet of white clear PTFE film:
| Property | Unit | High-density | Common |
| Tensile strength | MPa | ≥30 | ≥10 |
| Elongation at rupture | % | ≥30 | ≥100 |
| 1MHz dielectric loss tangent | 2.5×10-4 | -- | |
| 1MHz dielectric constant | average 1.8-2.2 | -- | |
| Dc breakdown voltage (Normal temperature) | KV/M | average 200 | average 30 |
| lowest 40 |
Specification of white clear PTFE film:
| Item | Thickness(mm) | Thickness Tolerance | Width(mm) | Item | Thickness(mm) | Thickness Tolerance | Width(mm) |
| High-density | 0.015 | 0~+0.01 | 10-120 | Common | 0.03 | 0~+10% | 50-300 |
| 0.02 | 0.05 | ||||||
| 0.03 | 0.08 | ||||||
| 0.04 | 0.10 | ||||||
| 0.05 | 0.15 | ||||||
| 0.07 | 0.20 | ||||||
| 0.08 | 0.25 | ||||||
| 0.90 | 0.30 | ||||||
| 0.10 | 0.40 | ||||||
| 0.15 | 0.50 |
PTFE film sepecification :
the specification can be customized , the thickness more than 0.03mm .
1. Temperature resistance : It is able to work stably between -180°C to +260°C.
2. Excellent chemical corrosion resistance: Applicable medium includes oil, acid solution,alkali and almost all chemical materials.
3. Excellent non-sticky property: With low friction coefficient it easier to remove those resin, dopes, oil and other sticky things.
4. Anti-aging, weathering resistance.
5. Excellent insulation property.
6. Filled material: Filled PTFE products has more outstanding performance by adding filler such as glass fiber, carbon fiber, copper powder, graphite, carbon powder, ceramic fiber, metal powder, polyamide.
Product Description
MAIN PRODUCT
Company Information
Packaging & Shipping
FAQ
1. Q: What is your MOQ ?
A: For seamless belt:. normal size 1000pcs, customized size 3000pcs. For PTFE fabric: our recent style 20s.q.m., customized specifications: 300s.q.m.For adhesive Tape: 200 roller per sizeFor silicone rack guard: 3000pcs And also we can support you for some trial order, details pls contact us for discuss.
2. Q: How about the sample charge?
A: Recently sample: free of charge, but freight will be collected Customized sample: need sample charge, but we will refund if we fixed official orders later.
3. Q: How about sample time?
A: For existing samples, it takes 1-2 days. For Customized samples, it takes 7-10days.
4. Q: How long is the production lead time?
A: It takes 15-30 days for MOQ.
5. Q: How much is the freight charge?
A: It base on the order qty and also shipping way! Shipping way is up to you, and we can help to show the cost from ourside for your referenceAnd you can choose the cheapest way for shipping!
