factory direct supply Double-inlet CY125 air

Product Application

This series low-noise centrifugal fan which we absorbed advanced technologies at home and abroad. all the structural parts of this fan are using the mold production, and the impeller have been static and dynamic balance proofread.

The impeller and scroll are all powder sprayed, the surface is smooth, bright and corrosion-resistant. The motor cover is also special handled, which helps the cover free from oxidized.

our centrifugal fan are little vibration, low noise, large air volume, easy to install and debug.

Main Features

1.Axial fan motor with feature of ,stable running,low noise,high effciency
2.Protector calss:IP44/ IP54
3.Insulation grade: B/F
4.Used in ambient temperature: -30 to 60 degree.c
5.life time: 30000 to 50000 hours
6.All Beron fans have passed CE and Rohs
7.Size: 200mm to 900mm

CY100

Name: air blower

Brand:Dragonpower

Original: China

Single-inlet

CY120

Name:air blower
Brand: :Dragonpower
Original: China
Single-inlet

CY180

Name: air blower
Brand: Dragonpower
Original: China
Single-inlet

CY150

Name: air blower
Brand: Dragonpower
Original: China
Single-inlet
