Product Description


 Brief description

JK2511 is a DC low ohm test meter with intelligence, wide range, precision, JK2511 can be suitable for transformer and inductor copper resistance, relay contact resistance, switches, connectors, wire resistance, contact resistance competent solder contact resistance, PCB line and welding hole resistance, metal detection, etc. Applied to the production line, it can use HANDLER interface and GPIB interface (option) output signal, in order to improve production line automation testing capability.


Features

*   High measurement speed
*   Easy operation
*   direct in reading
*   highly precise and better cost effectiveness.
*   minute extension

Specifications























































Model JK2511
Basic accuracy0.05%  reading value + 2 dgts
Measurement  range0.01 mΩ — 1.9999 KΩ
Test current100 mA,10 mA,1 mA,100 μA,10 μA,1 μA
Range20 mΩ, 200 mΩ, 2 Ω, 20 Ω, 200 Ω, 2 kΩ,
Range resolution10 μΩ, 100 μΩ, 1 mΩ, 10 mΩ, 100 mΩ,
Measurement speed (meas /sec)Fast: 10, Slow: 2.5
Ranging modeAuto, Hold
Trigger modeInternal, Manual, External
FunctionTop/bottom limitation, pass or reject, ranged locking, reset and data protection for power down function
Ordering information
Accessoryterminal Kelvin test clip leads,power line
