ZRAY-A 4 цветная печатная машина глубокой
- Категория: Rotogravure Printing Machines >>>
- Поставщик: Ruian,Toyo,Imp,And,Exp,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.27 $* | 0.50 $* |
| Aug-19-2025 | 0.34 $* | 0.49 $* |
| Jul-19-2025 | 0.26 $* | 0.43 $* |
| Jun-19-2025 | 0.42 $* | 0.31 $* |
| May-19-2025 | 0.17 $* | 0.76 $* |
| Apr-19-2025 | 0.14 $* | 0.22 $* |
| Mar-19-2025 | 0.36 $* | 0.90 $* |
| Feb-19-2025 | 0.34 $* | 0.29 $* |
| Jan-19-2025 | 0.98 $* | 0.40 $* |
Характеристики
Ruian Toyo
Why Choose Us
Products Description
Type | ZRAY-A4800 | ZRAY-A41200 |
Useful width of printing | 800mm | 1200mm |
Max width of material | 820mm | 1220mm |
Highest printing speed | 100m/min | 100m/min |
Highest machinery speed | 120m/min | 120m/min |
Max diameter of unwinding and rewinding | Φ600mm | Φ600mm |
Diameter of printing cylinder | Φ170~Φ300mm | Φ170~Φ300mm |
Register precision | ±0.2mm | ±0.2mm |
Total power | 65kw | 80kw |
Weight | 8600kg | 9500kg |
Overall dimensions(mm) | 8700×2600×2500 | 8700×3000×2500 |
* Product Application:
* This machine is suitable for roll plastic film,non-woven,thin leather,paper,aluminum foil,cloth and oter roll type material,it is a satisfying device to print wine case,shoe's bag and other bags
* This machine is suitable for roll plastic film,non-woven,thin leather,paper,aluminum foil,cloth and oter roll type material,it is a satisfying device to print wine case,shoe's bag and other bags
Main Features:
1)new type developed gear box,cluth gear box no stop to do register device,closed gear box
2)double layers,close heat oven,auto constant temperature system
3)unwinding use powder brake,auto tension control
4)rewinding and rewinding traction use powder cluth
5)rotary type double shaft in rewinding,automatic receiving and changing material,no stop
6)unwinding and rewinding use airshaft
7)pneumatic embossing system
8)traction press roll is pneumatic control type
9)main motor use inverter control
10) shaft type loading cylinder
1)new type developed gear box,cluth gear box no stop to do register device,closed gear box
2)double layers,close heat oven,auto constant temperature system
3)unwinding use powder brake,auto tension control
4)rewinding and rewinding traction use powder cluth
5)rotary type double shaft in rewinding,automatic receiving and changing material,no stop
6)unwinding and rewinding use airshaft
7)pneumatic embossing system
8)traction press roll is pneumatic control type
9)main motor use inverter control
10) shaft type loading cylinder
More Products
Our Services
Export to Pakistan, Bangladesh, India, Mexico, Jordan, Egypt, Vietnam, Nigeria, Saudi Arabia etc countries
Verified by Alibaba ,No Any Risks Of Payment
100% payment protection
100% payment protection
Able to provide
Mechanical test report
Video factory inspection
Guarantee product quality and integrity
Mechanical test report
Video factory inspection
Guarantee product quality and integrity
About Us
Production Process
Packing&Transport
FAQ
1. your company is a manufacture or a trading company?
We are a manufacture. We also have a trading company to do export work.
2. What is the terms of payment you accept?
We can accept the T/T payment, we need 30% of total amount as deposit,pay the 70% balance before delivery, we can also accept the L/C,western union,paypal,private account,cash and others.
3. Where is your factory located ? How can I visit there?
Our factory located in ruian city, the nearest airport is WENZHOU airport, the nearest train staion is RUIAN station. If you need,
we can we pick you up from airport or train station.
4,What about the warranty?
All of our machines have 1 year warranty, if need we send engineer to install and test, buyer pay for the round air-tickets, food,hotel and transport, pay our engineer 100usd / day / person as salary.
In warranty period, if spare parts broken, we exchange for free. after the warranty period, we supply the machine’s full life service, buyer pay for the material cost of exchanging spare parts and repairing.
We are a manufacture. We also have a trading company to do export work.
2. What is the terms of payment you accept?
We can accept the T/T payment, we need 30% of total amount as deposit,pay the 70% balance before delivery, we can also accept the L/C,western union,paypal,private account,cash and others.
3. Where is your factory located ? How can I visit there?
Our factory located in ruian city, the nearest airport is WENZHOU airport, the nearest train staion is RUIAN station. If you need,
we can we pick you up from airport or train station.
4,What about the warranty?
All of our machines have 1 year warranty, if need we send engineer to install and test, buyer pay for the round air-tickets, food,hotel and transport, pay our engineer 100usd / day / person as salary.
In warranty period, if spare parts broken, we exchange for free. after the warranty period, we supply the machine’s full life service, buyer pay for the material cost of exchanging spare parts and repairing.
