Б/у колесный погрузчик Caterpillar Cat 950H оригинал на
- Категория: Используемые погрузчики >>>
- Поставщик: SUPPLY,SOLUTION
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 1768533.7 $* | 1856960.11 $* |
| Aug-16-2025 | 1753671.96 $* | 1841355.72 $* |
| Jul-16-2025 | 1471300.50 $* | 1544865.64 $* |
| Jun-16-2025 | 1723948.88 $* | 1810145.14 $* |
| May-16-2025 | 1501024.5 $* | 1576075.18 $* |
| Apr-16-2025 | 1694225.80 $* | 1778936.7 $* |
| Mar-16-2025 | 1679363.78 $* | 1763331.65 $* |
| Feb-16-2025 | 1664501.1 $* | 1747726.21 $* |
| Jan-16-2025 | 1649640.15 $* | 1732122.48 $* |
Характеристики
RANXIANG MACHINERY
CONTACT US
DETAILED IMAGES
PRODUCT ANATOMIC
| Engine | |
| Number of Cylinders | 6 |
| Engine Make | 2236 |
| Engine Model | C7 ACERT |
| Net Power | 197 hp |
| Gross Power | 217 hp |
| Power Measured @ | 1800 rpm |
| Displacement | 439 cu in |
| Max Torque | 669 |
| Bore | 4.4 in |
| Stroke | 5 in |
| Net Power - ISO 9249 | 197 hp |
| Net Power - SAE J1349 | 195 hp |
| Net Power - 80/1269/EEC | 197 hp |
| Gross Power - SAE J1995 | 217 hp |
| Engine Model | Cat C7 ACERT |
| Flywheel Power | 197 hp |
| Peak Torque - 1,400 rpm - Net | 669 lb ft |
| Operational | |
| Operating Weight | 40435 lb |
| Fuel Capacity | 83 gal |
| Hydraulic System Fluid Capacity | 29 gal |
| Engine Oil Fluid Capacity | 7.9 gal |
| Cooling System Fluid Capacity | 11 gal |
| Transmission Fluid Capacity | 9 gal |
| Front Axle/Diff Fluid Capacity | 9.5 gal |
| Rear Axle/Diff Fluid Capacity | 9.5 gal |
| Static Tipping Weight | 27483 lb |
| Turning Radius | 23 ft in |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 amps |
| Rear Axle Oscillation | 26 degrees |
| Tire Size | 23.5R25 |
| Transmission | |
| Transmission Type | Powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
| Max Speed - Forward | 23 mph |
| Max Speed - Reverse | 24.9 mph |
| Forward - 1 | 4.3 mph |
| Forward - 2 | 7.9 mph |
| Forward - 3 | 13.9 mph |
| Forward - 4 | 23 mph |
| Reverse - 1 | 4.7 mph |
| Reverse - 2 | 8.6 mph |
| Reverse - 3 | 15.2 mph |
| Reverse - 4 | 24.9 mph |
| Weights | |
| Operating Weight | 40435 lb |
| Tires | |
| Tires | Choose from a variety of tires to match your application. |
| Buckets | |
| Maximum Bucket Capacity | 4.5 yd3 |
| Bucket Capacities | 2.5-3.5 m3 3.25-4.5 yd3 |
| Bucket Width | 9.6 ft in |
| Capacity - Reference bucket | 4 yd3 |
| Type - Reference bucket | General purpose |
| Breakout Force - Reference Bucket | 37125 lb |
| Hydraulic System | |
| Pump Type | Piston |
| Relief Valve Setting | 1000 |
| Pump Flow Capacity | 71 gal/min |
| Raise Time | 6.2 sec |
| Dump Time | 1.3 sec |
| Lower Time | 2.5 sec |
| Hydraulic Cycle Time - Total | 10 s |
| Hydraulic Cycle Time - Lower, Empty, Float Down | 2.5 s |
| Hydraulic Cycle Time - Raise | 6.2 s |
| Hydraulic Cycle Time - Dump | 1.3 s |
| Steering System - Pump Type | Piston |
| Bucket/Work Tool System - Pump Output | 71 gal/min |
| Bucket | |
| Breakout Force | 37125 lb |
| Dump Clearance at Max Raise | 9.6 ft in |
| Bucket Width | 9.6 ft in |
| Bucket Capacity - heaped | 4 yd3 |
| Bucket Capacity - struck | 3.5 yd3 |
| Axles | |
| Front | Fixed front |
| Rear | Oscillating +/- 13? |
| Maximum Single-Wheel Rise and Fall | 18.5 in |
| Brakes | |
| Brakes | Meets required standards. |
| Dimensions | |
| Length with Bucket on Ground | 26.2 ft in |
| Width Over Tires | 9.2 ft in |
| Height to Top of Cab | 11.4 ft in |
| Ground Clearance | 1.4 ft in |
| Wheelbase | 11 ft in |
| Hinge Pin - Max Height | 13.1 ft in |
| Reach at Max Lift and Dump | 4 ft in |
| Wheel Base | 11 ft in |
| Height - Top of ROPS | 11.3 ft in |
| Height - Top of Exhaust Pipe | 132.6 in |
| Centerline of Rear Axle to Hitch | 66 in |
| Height - Top of Hood | 97 in |
| B-Pin Height - Standard | 13.1 ft in |
| Centerline Rear Axle to Edge of Counterweight | 6.5 ft in |
| Rack Back - Maximum Lift | 59.5 degrees |
| Rack Back - Carry | 45 degrees |
| Rack Back - Ground | 38.5 degrees |
| B-Pin Height - High-Lift | 14.8 ft in |
| B-Pin Height - Carry - Standard | 1.5 ft in |
| B-Pin Height - Carry - High-Lift | 2 ft in |
| Height - Center Line of Axle | 2.5 ft in |
| Dump Angle at Maximum Lift | 48.2 degrees |
| Operating Specifications | |
| Dump Clearance | 9.6 ft in |
| Breakout Force | 37125 lb |
| Static Tipping Load - Full Turn - Bucket | 24068 lb |
| Static Tipping Load - Full Turn - Forks | 9421 lb |
| Service Refill Capacities | |
| Cooling System | 11 gal |
| Crankcase | 7.9 gal |
| Hydraulic Tank | 29 gal |
| Fuel Tank - Standard | 83 gal |
| Transmission | 9 gal |
| Differential - Final Drives - Rear | 9.5 gal |
