 1.Why to make the charcoal ?( briquette)

Due to the rapid increase in the need of energy source, more people start to become interested in Charcoal / Biomass Briquette business. It’s renewable, Eco-friendly Energy especially for agricultural countries.

Charcoal / Biomass Briquette investment is a best project to generate revenue from agro-forestry waste and to produce Green Energy to save the global environment. The awareness of using Eco-friendly & Non-conventional Bio-coal / Bio-fuel is increasing day-to-day due to the increasing of the conventional fuel cost.

Briquettes (also known as white Coal)  is an ideal fuel which substitutes coal, fire, wood lignite and other conventional fuels for heating steam generation. The demand of white coal has emerged from the shortage of conventional fuels like coal, oil, wood, etc. The shortage of this conventional fuel is increasing day by day; thus it indicates a golden future for alternative fuel.

What can be briquetted( making charcoal)

the raw material of the eco-friendly hard wood shaving sawdust powder briquette making machine equipments line could be :
Almost any biomass can be briquetted. Briquetting plants set so far in India are using Saw Dust, Bamboo dust, Bagasse, Cotton Stalk, Coffee husk, Groundnut Shell, Mustard Husk/Stalk, Pine Needles, Rice Husk, Sugar Mill Waste, Jute waste, Coir pith and other wastes & residues like Castor Shell, Red Gram Stalk, Tobacco stem, Tea Waste, Sander Dust, Tree Bark, Wild Grasses & Shrubs and Sander dust etc. can be also be briquetted individually or in combination without using any binder.

How to briquette?( The related machine of hard fire wood waste sawdust briquette producing machine for European Market )

Raw material:

Raw material : like Saw Dust and other raw material (above)

Cushing:( wood crusher of eco-friendly hard wood shaving sawdust powder briquette making machine equipments line )

Cushing machine prepare suitable size raw material for biomass briquetting plant. The required size for briquetting is 3-5mm. if the raw material with larger size, and the raw material should be chipped by the wood chipper first, then crushing the small shippers to sawdust .

Drying (sawdust dryer of eco-friendly hard wood shaving sawdust powder briquette making machine equipments line )

Drying machine prepare suitable moisture raw material for biomass briquette press.

Moisture of the raw material is important for making good briquettes. The proper moisture of the raw material should be 8-12%.If raw material has high moisture it should be reduced by Sun drying or using the dryer for drying

Briquetting (briquette machine of eco-friendly hard wood shaving sawdust powder briquette making machine equipments line )

Biomass briquette machine can process the raw material to briquettes with different shapes and diameter. Briquettes are made by grinding Biomass and sawdust into a homogeneous pulp and forming this into a briquette under very high pressure. High pressure & pressing releases one of the natural components of wood - lignin which has the property of becoming liquid at high pressure (temperature) and, as it subsequently cools, it binds the wood together in its new form Briquettes.

Semi-finished product: briquette stick

After the processing of drying, compressing under the high pressure and temperature, the biomass briquette is characterized by high density, small in size, better combustion, capable as the substitute for the superior coal or firewood. This bio-fuel briquette is 45-80mm in diameter, occurs in the hollow quadrangular or hexagonal cylinder or hollow hexagonal with a 15-20mm hole through the body.

carbonizing ( carbonization stove of eco-friendly hard wood shaving sawdust powder briquette making machine equipments line )

The semi-finished product can be used as fuel, however, if you want to change the semi-finished product to the charcoal, we should put the semi-finished product to the carbonization stove, and after 6-24hours carbonizing , the chemical structure of the wood briquette will be changed by the high-temperature, and after long time heating, changing and decomposing, then we will get the black charcoal, combustible gas, and wood tar.

Finished product :

The charcoal output by briquetting press is a utilization of regenerated waste energy, with the higher heat than other charcoals which is made of the similar materials, smoke-free, tasteless, non-toxic. The charcoal maintains the cleanliness and hygiene, and is suitable for family heating and barbecuing. There is a huge need in the international market, for it is capable as the substitute for the superior coal or heavy oil to the Industrial steam boiler, or the industrial raw material for the further processing into the activated carbon, mosquito coils and explosives

introduction of the hard fire wood waste sawdust briquette producing machine for European Market

eco-friendly hard wood shaving sawdust powder briquette making machine equipments line make the biomass material into briquettes. After the well preparement  of raw material, briquetting is easy at right operation of biomass briquette press. When machine rise to over 300 centigrade, the material can be feeding continuously into briquetting press. First, the color of briquettes may be a little dark even black, but after a while, the color will be light to normal level coming out of biomass briquette machine.

advantage of the eco-friendly hard wood shaving sawdust powder briquette making machine equipments line

• No binder or noxious chemical need to use.


• reasonable design of the hopper height , reduce the working intensity of the labour


• automatic electric heating device,can adjust raw material moisture.ensure that the material forming stability,improve the work efficiency


• main parts of the machine made from wear resistant material(, the machine can working 24 hours per day Change the three bearing into four, increased the stability of the machine


• Change the lubrication method, (maintenance much easier                                                                                 change the mould barrel structure, reduce the friction between the machine and raw material,increase the final product density


• Invented a break system which can guarantee to make the length of Briquette sticks same


• control panel in both Chinese and English more easier for operate

structure of the eco-friendly hard wood shaving sawdust powder briquette making machine equipments line

The main machine include the electrical motor, heating system,  switchboard, Temperature control device, rack, transmission lubrication system, the screw propeller, molding barrel, etc.

customers of the  eco-friendly hard wood shaving sawdust powder briquette making machine equipments line

after 25 years development, and we have export our products to more than 150 areas and countries

 Gongyi Xiaoyi Mingyang Machinery Plant is one of the largest and earliest manufacturers of the biomass energy equipment ( biomass briquette machine line, charcoal making production line, wood pellet production line and the related machinery)

 We are professional

1) more than 120 experienced workers, over 12000 square meter workshop,

2) high level standard workshop, advanced producing equipment, Experienced technicians, fine workmanship with 25 year working experience

3)produced 6 production line, more than 150 kinds of machines, awarded 10 patents in China

 We are confident

1)Products are widely accepted in both domestic and world market ,export to more than 150 countries

2)have been get the CE, SGS, ISO9001 :2008 and the other international quality standard .

 We are fast and efficient

1) We have the experienced workers and efficient assembly line,  and we have a long-term stable cooperation in logistics providers. So we never delayed for the delivery

2) We have the efficient management system,  each department cooperated smoothly and efficiently .

3) We have the professional sale service team to give you more fast and efficient service

We are tolerably thoughtful

1) We have stock for based goods, accessories in stock to meet you need,stocked your samples and all the details of the goods of the next order.

2) We have strict inspection personnel and process, and we are strictly ensure the quality of the international standard

3) We have the test center of the machine, Each machine will running before delivery

4) recommend clients for free, offer the layout drawing and the profit table and  install video and free stuff training

We are carefulness and honest

1) We pay attention to each working step and each parts of the machinery to give you high level products

2) During the past 25 years, our products are deeply welcome in the domestic and oversea market, and also gained lots of honors

We are dedicated and innovative.

1) We have one outstanding working team for the research and development of the machinery

2)We believe the idea of "pursue the perfect, customer---the highest" could ensure the quality.
