Main Features of screw Sand Washing Machine :
1. Simple structure, the impeller bearing is isolated from water, greatly to prevent the bearing due to flooding, sand and pollutants lead to the damage.
2. There is little loss for medium-sized and fine sand or fine stone powder. The product is met to national standards, such as "sand for construction".
3. There is no other wearing part except the screen mesh.
4. Long service life and few times for maintenance.
Working Principle:
When the machine is working, the material goes into the input part. It will push the material to the output through the machine. Surface dust and impurity are removed when the material from the input part to the output part is pushed, mixed and washed. The final product goes out through the discharge outlet and the mud and impurity will go out through overflow part.
Model | Spiral Diameter (mm) | Spiral Length (mm) | Spiral Speed (m/rin) | Processing capacity (t/h) | Matching Motor (kw) | Dimensions (m) |
XS0760 | 750 | 6000 | 18 | 15-30 | 7.5 | 7.6*1.4*1.5 |
XS1075 | 1000 | 7500 | 18 | 30-50 | 15 | 9.6*2*2.2 |
XS1275 | 1200 | 7500 | 16 | 50-80 | 18.5 | 9.8*2.1*2.2 |
XS1575 | 1500 | 7500 | 16 | 80-120 | 30 | 10.3*2.3*2.2 |
XS1590 | 1500 | 9000 | 16 | 120-150 | 30 | 11.8*2.4*2.2 |
Double spiral sand washer
Model | Spiral Diameter (mm) | Spiral Length (mm) | Spiral Speed (m/rin) | Processing capacity (t/h) | Matching Motor (kw) | Dimensions (m) |
XS1500 | 750*2 | 6000 | 18 | 60-80 | 7.5*2 | 7.6*2.8*1.5 |
XS1075 | 1000*2 | 7500 | 18 | 80-150 | 15*2 | 9.6*4*2.2 |
XS1275 | 1200*2 | 7500 | 16 | 150-220 | 18.5*2 | 9.8*4.2*2.2 |
XS1575 | 1500*2 | 7500 | 16 | 180-280 | 30*2 | 10.3*4.6*2.2 |
we can provide valuable successful cases for your reference.
Deliver A Customised Processing Plant Which Will Add Maximum Value for Your Business,Modular Wet Classification For A Variety Of Industrial Sands. Material Testing Lab.100+ Project Engineers,Service Support Team,Lowest Running Costs.
Henan Victory Machinery Co., Ltd is located in the important central hub city of China – Zhengzhou. It is a high-tech enterprise provides "environmental mine construction and operation" as the main and integrates design and development, machinery manufacturing, equipment procurement, management services, mine operations, mining materials procurement management and industry resource integration. The company's business scope covers all over the world.
Are you want more detail of this machine? Please send your inquiry details in the below for free sample, Click "send" Now! The best price you may get early.
