Акушерское гинекологическое устройство для обследования влагалища hd цифровые фотографии медицинский
- Категория: Ультразвуковое, оптическое, электронное оборудование >>>
- Поставщик: Beijing,Oriental,Wison,Technology,Co.,Limited
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-16-2025 | 0.17 $* | 0.92 $* |
| Aug-16-2025 | 0.44 $* | 0.63 $* |
| Jul-16-2025 | 0.99 $* | 0.27 $* |
| Jun-16-2025 | 0.3 $* | 0.75 $* |
| May-16-2025 | 0.1 $* | 0.95 $* |
| Apr-16-2025 | 0.28 $* | 0.14 $* |
| Mar-16-2025 | 0.16 $* | 0.47 $* |
| Feb-16-2025 | 0.17 $* | 0.99 $* |
| Jan-16-2025 | 0.12 $* | 0.3 $* |
Характеристики
Recommend Products
Why Choose Us
Product Description
Obstetrics Gynecology device vagina examination hd digital pictures meddiccal digital colposcope
It is image workstation management system combining computer technology and electric colposcope. It is a new product collects
digital imaging technology and colposcope technology. It is applied for gynecology inspection. This technology is different from
traditional colposcope inspection. It cancels ocular and breaks through limit of optic colposcope inspection.
digital imaging technology and colposcope technology. It is applied for gynecology inspection. This technology is different from
traditional colposcope inspection. It cancels ocular and breaks through limit of optic colposcope inspection.
Product Paramenters
colposcope digital image system | ||||
Camera resolution | (points) | 550000 | ||
Horizontal output resolution | (line number) | 550 | ||
Video resolution | 720x576 | |||
Frame/second | 25 | |||
Photo resolution | 720x576 | |||
Output interface | Video | |||
Focus type | auto /manual /tracking | |||
Work distance | auto focus | 200-400mm | ||
manual focus | 150-450mm | |||
Depth of field | 3.9-85.8mm | |||
Optic magnification | 22 | |||
Digital magnification | 16 | |||
Diameter of vision | 10-160mm | |||
Angle of vision | 2.4-49.5 | |||
Light source | white LED | |||
Brightness | >3000lm | |||
Temperature | color temperature:6500k | |||
Filter | red,blue,green | three area (three primary colors), green filter | ||
White balance | auto/special /indoor /outdoor/manual/key control auto | |||
No -stop run time | more than 8h | |||
Light source life | more than 50,000h | |||
Software | COLPOSCOPE, VN,RU,EN,ESP, CN FIVE LANGUAGE,suitable for XP, WIN7 operation system | |||
Details Images
Features
1.Fashionable appearance, convenient design.
2.Adopt the 1/4 color digital CCD camera with high resolution and clarity.
3.Bulbs adopt super cold LED light source .
4.There are “freeze, filter, zoom in, zoom out, white balance” buttons on the camera for the speedy automatic functions.
5.Professional green-filter techniques.
6.Image freeze.
7.White balance.
8.Auto focus.
9.Timing of acetic acid and iodine reaction tests.
10.Powerful image software and workstation system
2.Adopt the 1/4 color digital CCD camera with high resolution and clarity.
3.Bulbs adopt super cold LED light source .
4.There are “freeze, filter, zoom in, zoom out, white balance” buttons on the camera for the speedy automatic functions.
5.Professional green-filter techniques.
6.Image freeze.
7.White balance.
8.Auto focus.
9.Timing of acetic acid and iodine reaction tests.
10.Powerful image software and workstation system
General Insturctions | ||
Properties | Obstetrics & Gynecology Equipments | |
Type | Gynecology examination | |
Light source | LED | |
Camera system | Camera system | |
Gynecology examination | Colposope | |
Endoscope | Video colposcope | |
Colposcope | Ditigal and electronic colpsocope | |
Connect computer | Desktop&laptop | |
Optional
Monitor: LCD screen
Printer
Trolley
Type A :PC
Type B :all in one PC
Wireless video transmission, without any wire interference, wireless transmission distance is 30m
Barcode scanner
Printer
Trolley
Type A :PC
Type B :all in one PC
Wireless video transmission, without any wire interference, wireless transmission distance is 30m
Barcode scanner
Specifications
Gynecology examination medical colposcope
1. Wirless transmission.
2. DC and battery power supply
3. scan probe
4. sony camera
1. Wirless transmission.
2. DC and battery power supply
3. scan probe
4. sony camera
Operation
1. It is prohibit to do any gynaecology examinations such as vaginal a day before the colposcope examination
2. It is prohibit to use vaginal drug two days before the colposcope examination
3. It is prohibit to do colposcope examination during menstrual period.
Software can be compatible with Windows XP, Windows 7/8, 32/64 bits
2. It is prohibit to use vaginal drug two days before the colposcope examination
3. It is prohibit to do colposcope examination during menstrual period.
Software can be compatible with Windows XP, Windows 7/8, 32/64 bits
Operation System
Windows XP
Windows 7/8
32/64 bits operating system
Windows 7/8
32/64 bits operating system
Our Advantages
Wireless transmission
DC and battery power supply
Combined trolley and bracket ( Type A/Type B)
Scan probe
LCD screen
Standard Configuration
camera
Image capture system (Software))
Image control system (Software)
Bracket
Footswitch
Packing case
DC and battery power supply
Combined trolley and bracket ( Type A/Type B)
Scan probe
LCD screen
Standard Configuration
camera
Image capture system (Software))
Image control system (Software)
Bracket
Footswitch
Packing case
Application
Gynecology examination medical colposcope
1.Suitable for gynecology examination and cervical cancer early find
2.On the clinical, checkup with vulva, vagina, cervix and other part
2.On the clinical, checkup with vulva, vagina, cervix and other part
