Машина Для Экстракции Масла CBD для большой производственной

Product Application

Supercritical fluid extraction (SFE) is a kind of green separation technology with strong applicability. Supercritical CO2 extraction uses CO2 as solvent. The supercritical fluid of CO2 has large density and dielectric constant, and has great solubility to substances. And it changes rapidly with the change of pressure and temperature. Therefore, not only the solubility of some substances is selective, but also the solvent and extract are easily separated.
Compared with the conventional separation method, it has the advantages of low extraction temperature, high selectivity, high efficiency, low energy consumption and no pollution. It is especially suitable for the extraction of liposoluble, high boiling point and thermosensitive substances, as well as for the fine separation of different components. Widely used in biopharmaceutical, food industry, health products, cosmetics, spices and other industries.

Main Features

1) Low critical temperature suitable for extraction and purification of heat sensitive compound.
2) Being capable to provide inert environment to avoid oxidation of products and affection of effective content of extracts.
3) Fast extraction speed, no toxicity, non-flammable, safe application and no pollution upon environment.
4) No residue of solvent, no nitrate and ions of heavy metal.
5) The press ring of the extraction kettle can be opened quickly; O-ring is imported with service period over 4 months.
6) CO2 can be used in circulation.
7) It can be designed and manufactured as per GMP standard.
8) The pressure stabilizing system of the extraction kettle is imported back-pressure valve.
9) It can be controlled with computerized automatic control system (temperature, pressure, flow etc.)
10) All valves of the device are under special heat treatment so they are robust and durable.

Machine Parts

Name:  Extractor

Brand: Chengdong

Original: China

Our extractor adopts hydraulic quick opening structure, which has strong sealing performance and can greatly improve the utilization ratio of products.

Main Parts

Name: Separator

Brand: Chengdong

Original: China

With different design pressure and different solubility, the substances can be precipitated more thoroughly.

Machine Parts

Name: CO2 Circulation Storage Tank
Brand: Chengdong
Original: China

Recovery of CO2 after each operation and then high-pressure reuse, cost savings, environmental protection.

Machine Parts
Name: CO2 High Pressure Pump
Brand: Chengdong
Working pressure: 30-70Mpa

We will specially customize this kind of high pressure pump according to the product model.
