Гибочный станок Shijiazhuang Hebei Cnc
US $9600-$22000
Высококачественный широко используемый станок для сгибания арматуры TZ730/станок проволоки/автоматический сгибающий горячая Распродажа
- Категория: Rebar Bending Machine >>>
- Поставщик: Hebei,Taizhe,Machinery,Equipment,Trading,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-17-2025 | 11332.51 $* | 11559.59 $* |
| Jul-17-2025 | 9191.94 $* | 9375.96 $* |
| Jun-17-2025 | 11154.69 $* | 11377.43 $* |
| May-17-2025 | 11065.69 $* | 11286.62 $* |
| Apr-17-2025 | 8834.0 $* | 9011.71 $* |
| Mar-17-2025 | 10886.8 $* | 11104.11 $* |
| Feb-17-2025 | 10797.96 $* | 11013.78 $* |
| Jan-17-2025 | 10708.98 $* | 10922.11 $* |
Характеристики
TOP quality Widely used TZ730 Rebar bender/wire bending machine/Automatic stirrup bender hot sale hoop bender price
Product Description
Automatic stirrup bending machine CNC servo control system, can be done automatically reinforced straightening, cut to length,bending hoop, cutting and other process, the maximum diameter of 14mm can bend steel, continuous production of any planar shape of products, widely used in construction, a large steel plant and other fields. Further equipment since production improved after a few more perfect products and better meet the actual needs of steel processing.
Features
1.Automatic wire feeding system ( CNC ).
2.Moveable air compressor design, to ensure better cooling effect, easy transportation and installation
3.Split, multi-blade design to reduce consumption costs
4.Large storage capacity can save 500 processing geometric graphics, high degree automation
5.Automatic double wire intake system, high processing efficiency
6. High power feeding motor to ensure bending bar accuracy.
7.The intelligent fault identification alarm system maintenance more convenient
8. Aerodynamic design observation door, easy adjustment and maintenance, and more security and fast.
9.Heavy-duty design line planes, equipped with a brake and buffer device can prevent chaotic lines caused by downtime
10. High quality special material and high treatment to make straightening wheels, traction wheels, the metering wheel, longer
life with lower operating costs
11. TZ730 type - Touch-screen pannel, easy to operate, and more fast.
2.Moveable air compressor design, to ensure better cooling effect, easy transportation and installation
3.Split, multi-blade design to reduce consumption costs
4.Large storage capacity can save 500 processing geometric graphics, high degree automation
5.Automatic double wire intake system, high processing efficiency
6. High power feeding motor to ensure bending bar accuracy.
7.The intelligent fault identification alarm system maintenance more convenient
8. Aerodynamic design observation door, easy adjustment and maintenance, and more security and fast.
9.Heavy-duty design line planes, equipped with a brake and buffer device can prevent chaotic lines caused by downtime
10. High quality special material and high treatment to make straightening wheels, traction wheels, the metering wheel, longer
life with lower operating costs
11. TZ730 type - Touch-screen pannel, easy to operate, and more fast.
Recommended application industry:
This machine is widely used in the construction industry,large steel processing plants,and high-speed railway,high way,water conservancy construction,etc.
Specification
Model | TZ530 | TZ730 | TZ745 | TZ750 |
Single round bar Diameter | 4-10mm | 4-12mm | 4-14mm | 4-14mm |
Single ribbed bar Diameter | 4-10mm | 4-10mm | 4-12mm | 4-12mm |
Double round bar Diameter | 4-8mm | 4-10mm | 4-12mm | 4-12mm |
Double ribbed bar Diameter | 4-6mm | 4-8mm | 4-10mm | 4-10mm |
Max Bending angle | 180° | 180° | 180° | 180° |
Length Accuracy | ±1mm | ±1mm | ±1mm | ±1mm |
Max bending speed | 1460°/S | 1460°/S | 1460°/S | 1460°/S |
Angular Accuracy | ±0.1° | ±0.1° | ±0.1° | ±0.1° |
Average power | 5kw/h | 5kw/h | 5kw/h | 5kw/h |
Total Power | 18.5KW | 24.5KW | 33.5KW | 33.5KW |
Steel processing shape | 500 | 500 | 500 | 500 |
processing efficiency | 1700-1800PCS/H | 1700-1800PCS/H | 1800-2200PCS/H | 1800-2200PCS/H |
Weight | 1700kg | 1800kg | 2000kg | 2000kg |
Dimension | 3600*1800*900mm | 3200×1000×1700mm | 3500*1200*2200mm | 3500*1200*2200mm |
Detailed Images
Company Information
Warranty
18months Quality warranty period (after put into operation formally).
Provide technical guide for stirrup bending machine forever.
After Quality Warranty period of stirrup bending machine, will provide the spare parts with cost price.
All the machines provided by our factory will be tested before ship.
Packaging & Shipping
We test the automatic stirrup bender machine before it is packaged and transported:
One set Automatic Stirrup bender machine
1, could packed in iron frame, than cover by tarpaulin
2, could packed in wooden case,
Machine packed in two wooden cases, total diminsion 17.76CBM, gross weight 3166kgs.
3, also could packed in nude
Customer can select the spare parts:
air compressor and flexible framework
Our Services
Pre-Sales Service
* Inquiry and consulting support.
* Sample testing support.
* Visit our Factory.
* Sample testing support.
* Visit our Factory.
After-Sales Service
* One year warranty for whole machine(after put into operation formally)(not including wearing parts ),life-long maintenance and technical support.
* All the machines sold in the country shipped with user-friendly English operation video and instruction.
* Training how to instal the machine, training how to use the machine.
* All the machines sold in the country shipped with user-friendly English operation video and instruction.
* Training how to instal the machine, training how to use the machine.
FAQ
1.Q:How long of the delivery time?
A:5 days for our own design.(motor:380v 50hz 3phases).
10 days for cusmoized model.
2.Q:How can we use the machine?
A:we will send the english user manual and video with the machine, if not enough, we can teach you online.
3. Q: How does your factory do regarding quality control?
A: We test our machine before shipping. Our factory has gained ISO9001:2008 authentication.
4.Q: How long is the warranty?
A: one year warranty and after sales service for whole life.
5.Q: how to pay for the product?
A: 100% irrevocable L/C at sight,
T/T 30% in advane and the rest 70% before shipment ,
Alibaba's on-line trade assurance order,
Western union is available.
6.Q:Can you make the english language or other language of the CNC control system for the customers?
A:Yes. Of course. We can make different language for the cnc control. Just tell us which language you need.
