Китайский Воздушный компрессор Hangzhou Shanli с сушилкой для

Standard Working Condition:

 Two types of the air-cooled refrigeration compressed air dryer:

Normal temperature (≤45°C) type & high temperature type( ≤80°C)

Main Technical Specifications:

 1) Pressure dew point: 2 - 10°C

 2) Rated operation pressure: 0.6 - 1.0Mpa

 3) Inlet air temperature: ≤45°C  ( ≤80°C high temp. type)

 4) Ambient temperature: ≤38°C

 5) Pressure drop: ≤ 5% of the working pressure

 6) cooling way: air cooled

 7) Air Capacity Range: 0.65-90Nm3/min

 8) Power supply: AC 380/220V 50Hz

 Note:  Any technical parameter can be changed according to your requirement.

To know more, pls contact ROBIN.

Main parts of the machine:

a) Air to air heat exchanger

b) Evaporator

c) Refrigerant compressor

d) Hot gas bypass valve

e) Expansion valve

f) Water separator

g) Condenser

h) Automatic drainage

i) Pressure protector for compressor

j) Condensing pressure regulator (water valve)

k) Pre-cooler

Features:

1) Low running cost, low pressure drop and steady dew point

2) Easy to install and maintain

3) Ideal for high environmental temperatures

4) Microprocessor control

5) Suitable for a range of air compressors

6) Can provide custom-made service

1. Quality warranty of 18 months should be offered after the shipment.

Introduction:

HangZhou SHANLI Purify Equipment Corporation was founded in 1997,shanli have near 20 years history in compressed air dryer field.Our company already get many patents in air dryer technology,and shanli can independently design,developing,produciton and sales.Shanli already get lots of honor in domestic market in past years.Although Shanli just start to export goods to oversea market in recetantly years,but we believe that shanli will be your valued supplier in air dryer industry.

Certification:

Workshop:

Q:Could make a brief introduction about Shanli ?

A:Shanli is a CE and ISO 9001:2008 certificated leading air dryer manufacture in China

    with more than 20 year experience with the most 31 patents.Shanli has been the supporting

    supplier for Atlas,Boge and Ingersoll Rand.We are already make export to 20 different countries

    and worldwide as active, mainly Middle East and Europe.

Q:How many technical guys in your company?

A:Over 30 prefessoinal technical staff.

Q:How many patents do you have?

A:Over 31 patents which is the most in China air dryer industry.

Q:What about the delivery and packing?

A;25 days delivery and common wooden case packing with fumigation

Q:Which trade terms do you use?

A: We commonly use FOB,CFR,CIF,DDU and DDP

Q:What about your warranty time?

A:18 months.
