4 осевой фрезерный станок с ЧПУ резка машины для резки нержавеющей


Поделиться:


Цена:5 600,00 $ - 5 900,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-18-2025 6664.25 $* 6997.3 $*
Aug-18-2025 6608.69 $* 6938.16 $*
Jul-18-2025 5544.52 $* 5821.50 $*
Jun-18-2025 6496.37 $* 6821.33 $*
May-18-2025 5656.35 $* 5939.28 $*
Apr-18-2025 6384.10 $* 6703.22 $*
Mar-18-2025 6328.45 $* 6644.49 $*
Feb-18-2025 6272.52 $* 6586.82 $*
Jan-18-2025 6216.5 $* 6527.26 $*

Характеристики


4 Axis Cnc Milling Cutting Machines for Stainless Steel


1.Features

1.   Use iron casting tempering technology for making machine body, good stiffness and working stability, less vibration.

2.Well compatibility: compatible for software CAD/CAM, such as type3/artcam/JDPaint/proe/ug.rtc

3.Heavy loading, non deformation, adopting imported double nut screw to ensure the engraving speed. Adopting Taiwan’s high-precision square linear guide, effectively imported the precision of carving.

4.Adopt high speed water cooling motor with invariably power, big torque,strong cutting, high-frequency and long-life. Available for continuous work for a long time.

5.Intelligent protection of the surface ; to prevent misuse,or software errors which may cause damage to the surface. Intelligent processing with cross-border protection to prevent the design of the layout over the processing area causing collision because of mechanical phenomenon.
6.General principles of tempering aging treatment of welding structure ,solid without deformation. Ganty mobile ,fixed work platform,materials on the table canbe arbitrary processed
7. Movable table design, good mechanical stability, high accuracy workpiece.



Product Description

2.Parameter

Working Area

600×600×200mm

Table Size

600×600mm

Worktable

T-slot table

Spindle Motor

4.5KW water-cooling spindle

2.2KW spindle with constant power

Rotating Speed

6,000 ~ 24,000rpm

Motor Drive

Japan Yaskawa Motors

Drive Mechanism

Table moved

Accuracy

±0.02mm

Max Motion Speed

30000mm/min

Max Engraving Speed

20000mm/min

Compatible CAD/CAM Softwares

Ucancam V8 / Type3 / Artcam

Control System

NC Studio



Collets Type

3.175mm, 6mm, 12.7 mm

Operating Voltage

3Phase AC380V, 50-60Hz

Net Weight

600 Kg

3.Application:

1).It is suitable for engraving,milling and drilling compactly all sorts of materials such as steel,copper,aluminum and plastics.

2). It can widely apply to automotive,injection mould,ironware mould and engrave mould industries.

3). It mainly use for engraving and milling molds,eyeglasses, watch,panel,badge,brand, graphics and words of three-dimensional and outside surface's sleeking of large size.

4).Engrave on various materials, such as organic glass,PVC sheet,gemstone,natural marble,aluminum composite panel, steel,iron,copper,alumium,plastic,etc.

4.Samples:

Mold machine samples.jpg

5.Details:

Metal mold cnc router.jpg

Hot Sale Products

Click the picture to check other hot sale products

main products1

Company Information

Customer visit

Jinan Firmcnc Equipment Co.,Ltd, the professional cnc router manufacturer in China, include ATC CNC router, Wood CNC Router, Stone CNC Router, Metal CNC Router, EPS CNC Router, 4 Axis CNC Router, 5 Axis CNC Router, and so on, which have passed the CE, SGS, ISO9001 etc. Our cnc routers are widely used for advertising, woodworking, mould, stone, metal industry.

We have our own factory and R & D team. Factory covers an area of about 2500 square meters, specializing in the production of various types of special-shaped machine.

China manufacturer



Packaging & Shipping

about usMode of transport

Firstly we will make sure machine clean before package,

then add Stretchy film for the whole machine and spare parts for better protection,

finally we will make export standard strong plywood case package according to your needs.

Our Services

1.Before sale

♦Our salesman will try to know more about your demands ,  including the max working size, main processing materials and the thickness , so we will offer you suit machine

2.During production

♦We will send the production the machine pictures for customer in time , customer can know more the detailed machine parts

3.Before shipping

♦The machine parts will be installed and tested by our professional technician, send the test video according to customer’s processing materials for customer confirmations

4.After shipping

♦We will check when the machine arrive your sea port or the approximate arrival date, so that the customer can know the arrival date and to prepare to pick the machine up

5.Teaching

♦The English manual and operating video will be sent to customers with the machine together, it will help customer how to operate the machine , it there is any question about the operation , we will have the professional technician to help them how to operate by online ,until the customer can use it freely

feedback_conew1_conew1Cooperation brand

FAQ

Q1: How can I get the best machine for me?
You can tell us your working material, detail work by picture or vedio so that we can judge whether our machine can meet your need or not. Then we can give you the best model depends on our years of experience.

Q2: This is the first time I use this kind of machine, is it easy to operate?
We will send you manual and guide vedio in English, it can teach you how to operate the machine. If you still can not learn how to use it,  we can talk by phone, video call ,email or other contact ways.
Q3: If the machine has problem in my place, how could I do?
We could send free parts to you in warranty period if machines have any problem under "normal use", and we provide engineers available to service machinery overseas.
Q4: This model is not suitable for me, do you have more models available?
Yes, we can supply many models. such as advertising cnc router, metal cnc router, wood cnc router, stone cnc router and so on.
Replacement of some part based on your need. The above are most popular. If it can not meet your requirement, then tell us. We have the ability to make specially according your requirement!

Q5:What's the guarantee, in case the machine breaks down?
The machine has 2 years guarantee. If it breaks down, generally speaking, our technician will figure out what the problem may be, according to client s feedback. Parts except for consumable parts will be replaced for free if the problems are caused by quality fault.
Q6:How about the documents after shipment?
After shipment, we ll send all original documents to you by DHL, including Packing List, Commercial Invoice, B/L, and other certificates as required by clients.
Q7:How long is the delivery time?
For standard machines, it would be 7-10 days; For non-standard machines and customized machines according to client s specific requirements, it would be 15 to 30 days.
Q8:How's the payment?
We provide L/C,D/A,D/P,T/T,Western Union,MoneyGram,Paypal payments for offline orders and online orders
Q9:Do You Arrange Shipment For The Machines?
Yes, dear esteemed customers, for FOB or CIF price, we will arrange shipment for you. For EXW price, clients need to arrange shipment by themselves or their agents.
Q10:How is the packing?
Water-proof plastic film package with foam protection in each corner
Solid Seaworthy Wood Box Package with Steel Belt
Save space as much as possible for container loading
