  Electrical insulated gloves



   This series of gloves is suitable for electrical equipment of different AC voltage levels for live operation. According to the operation requirements of different voltage grade, the user can select the insulated gloves of the adaptation level.

  This series of gloves make the import high-quality rubber as the main substrate. and all use vulcanized molding equipment, and are made by the most advanced glue injection technology, the gloves’ appearance is all hand shape.

  This series of gloves have the characteristics of good insulation performance, thin, soft, comfortable and safe and reliable.

   This series of gloves are tested in immersion and electricity one by one before they leave the factory.

    Different specification for your selection as following:



 Executive Standard: GB/17622-2008, This standard is equivalent to IEC60903-2002

Model	Max Working Voltage  AC/DC(KV)	Test Voltage AC/DC(KV)/3min	Minimum Tolerated Voltage (KV)	Maximum Leakage Current(mA)
Class 1 Red	7.5/11.25	10/20	20	≤16
Class 2 Orange	17/25.5	20/30	30	≤18
Class 3 Orange	26.5/39.75	30/40	40	≤20
Class 4 Orange	36/54	40/60	50	≤24



 Executive Standard:Q/12 JH 5052-2015

Model	Max Working Voltage   AC(KV)	Test Voltage AC/DC(KV)/3min	Minimum Tolerated Voltage AC/DC (KV)	Maximum Leakage Current (mA)
6KV Red	0.4	6/10	16/20	12
12KV Red	4.5	12/22	22/44	15
25KV Orange	21.75	25/35	35/65	18
35KV Orange	30	35/45	45/78	22
