Вертикальный цилиндрический хонинговальный станок


Поделиться:


Цена:*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-16-2025 0.79 $* 0.97 $*
Aug-16-2025 0.6 $* 0.99 $*
Jul-16-2025 0.66 $* 0.32 $*
Jun-16-2025 0.60 $* 0.51 $*
May-16-2025 0.79 $* 0.88 $*
Apr-16-2025 0.14 $* 0.55 $*
Mar-16-2025 0.17 $* 0.12 $*
Feb-16-2025 0.15 $* 0.50 $*
Jan-16-2025 0.35 $* 0.64 $*

Характеристики


Vertical Cylinder Honing Machine THM170








Features:



  • Hydraulic vertical honing machine with head provided with pneumatic system for an easy honing spindle longitudinal and transversal positioning on the workpiece.

  • The block supporting base is adjustable in the height and inclination to allow the assembling of flat and "V"blocks.

  • Honing spindle with steplessly variable ratation speed visualized on the control panel.





Parameter:



























































































Specification



Unit



THM170



Max. dia. of the hole honed



mm



φ170



Max. depth of the hole honed



mm



360



Spindle speed(stepless)



r.p.m



100-300



Roundness



mm



0.0025



Cylindricity



mm



0.005



Surface roughness




Ra0.2



Table longitudinal travel



mm



1100



Table cross travel



mm



80



Table max. loading



kg



200



Main motor



kw



1.1



Hydraulic station motor



kw



1.5



Coolant pump motor



w



90



Spindle reciprocation speed(stepless)



m/min



0-18



Overall dimensions(LxWxH)



mm



1820x1440x2170



Packing dimensions(LxWxH)



mm



2210x1610x2270



N.W/G.W



kg



1200/1400










Packaging & Shipping







Company Introduction


 .jpg





Export Cases







Exhibitions


 .jpg





Customers Visited


 .jpg





FAQ





Q: Why choose TIMEWAY MACHINE?
A: 1 . High quality with competitive price;
2 . Professional R&D team and 25 years export experience;
3 . Exported more than 60 countries;
4 . CE, ISO Certificates;
5 . 24 HOURS ONLINE SERVICE (SKYPE, WhatsApp, Wechat, Trademanager);
6 . 12 months quality warranty;
7 . Oversea engineers available for problem resolving;

Q: Do you have QC or any safety standards for your machinery?
A: yes, we have established a highly strict quality control department to guanrantee good quality.


Q: What's the MOQ?
A: 1 set (Only some low cost machines will be more than 1 set )


Q: What about the payment terms?
A: 1) T/T with 30% advanced payment, and 70% balance payment to be paid before shipment;
2) Irrevocable LC at sight;
3) Western Union, MoneyGram, etc.


Q: How about the warranty?
A: Warranty Period is one year after delivery. Even beyond the period, we will supply lifetime service for machine.
