Why Choose Compound Banbury Mixer Products from Lanhang
1. We're founded in 1992, with more than 20 years' professional experience
2. Fourtune global 500 companies' supplier, such as Dow Corning, Shin-Etsu...
3. Overseas service center available (in Europe, Japan, Dubai, etc.)
4. International CE, SGS, IAF, CNAS certification
5. National high-tech enterprise / products
6. We own various National Patent for Inventions Letters for rubber & plastic machinery
7. ISO9001:2008 management
Main Parameters of Our Intermeshing Compound Banbury Mixer
Model
LH-100Y
LH-145Y
LH-200Y
LH-250Y
LH-330Y
Chamber Volume (L)
100
145
200
250
330
Filling Coefficient
0.65
Rotor Type
Intermesh
Rotor Speed (r/min)
10-60
Rotor Speed Ratio
1:1.17
Max. Capacity (T/H)
1.36
2.2
3.05
4.2
5.0
Motor Power (Kw)
520
720
1100
1320
1700
Dimension (m)
6.6x2.8x4.4
7.5x3.1x5.5
8.1x3.5x5.4
8.2x3.8x5.5
10.0x4.7x6.6
Weight (T)
19
29
48
65
80
Application of Our Compound Banbury Mixer
This intensive mixer has a wide range of applications, including in mixing and refining Raw materials, such as raw rubber, synthetic rubber, resin, asphalt, cellulose, PVC or EVA into even mixed stock. The body and structure of this machine are strong and durable, making it suitable for heavy-duty Rubber & Plastic mixing and refining operations.
Features of 100L Compound Banbury Mixer
1. Intermeshing or tangential rotor
2. Rotors, mixing chamber, harmmer and parts which contacts with the material are overlayed with 5mm wear-resistant alloy (up to 50HRC)
3. Pneumatic or hydraulic type top mounted ram is optional
4. Falling type floating weight which is driven by gear and hydraulic oil tank with good sealing performance.
5. Inverted AC motor or variable speed DC motor is optional
6. Drop / side door discharging
7. Copper-ring and hydraulic sealing
8. 2-wing, 4-wing, 6-wing are available
9. Excellent dispersing effect
10. Best mixing rotor and chamber to guarantee 100% mixing effect
11. LG brand electrical parts, Mitsubishi brand PLC, ABB motor
12. Low noise, safe mixing
13. Maintenance friendly and long-life service
Description of Compound Banbury Mixer
The Banbury Mixer, which is invented by Fernley H. Banbury, was introduced to the rubber manufacturing industry in 1917. The machine is called a compounder, mixer, or blender. It mixes components together that do not readily blend but require a lot of energy to become homogeneous. The mixer is a batch operation and is used to blend rubber and plastics or many different materials with additives.
Working Principle of Compound Banbury Mixer
The materials to be blended are introduced through a hopper. A ram pushes the materials into the mixing chamber. Two counter-rotating rotors provide the mixing action, much like double dough hooks. The blended batch is discharged through an opening in the bottom of the mixing chamber to the next processing step. Improvements made over the years include many design changes to enable easier operation and maintenance.
Heat transfer is closely controlled in the modern Banbury Mixer. The rotors generate a lot of friction with the material, so mixing is generally an exothermic process, giving off heat to the environment. Some mixes absorb heat and become cooler, however. In many processing operations, heat may be added to the system.
Internal pressure is also controllable, and many mixing operations occur under increased pressures and temperatures. This capability is necessary for the mixer to act as a reactor chamber in the manufacture of many polymers. Compounding of rubbers or rubber recycling is often spoken of as mastication and softening. While those terms imply the first steps of human digestion, the rubber is usually not chemically changed.
Our Company Show Banbury Mixer for Rubber Compound
Our Certificates for Banbury Compound Banbury Mixer
Wood Pallet & Film Wrap ( Compound Banbury Mixer )
Our Services
Compound Banbury Mixer
1. One year warranty
2. Engineers available to service machinery overseas (installation, debugging, commissioning and maintenance.)
3. Overseas service center available (in Europe, Japan, Dubai, etc.)
