Stainless Steel Material Ultraviolet Sterilizer for Water Treatment









Special Features

* With stands a max. line pressure of 7 Kg/sq.cm.
* Based on quartz technology. Imported thick gauge quartz enclosures used for UV lamps.
* Special accessories like UV monitor, flow control system, audio alarm system, solenoid valve etc. are
provided as optional with all models.
* All UV lamps are situated, in the middle of water flow in the sterilizing chamber so as to give a through
exposure of UV rays to water.
* Imported powerful ultra violet lamps, germicidal type of 254 nm wavelength are used.
* All Models work on 110-240V, 50/60 Hz, 1 Ph. A. C. supply.
* Each model designed to give UV energy dose in excess of 30,000 micro-watts sec per sq.cm.
* Complete unit is available in fully factory assembled & tested condition.
* Both side open quartz tubes are used & each tube is firmly sealed & supported at both ends.
This eliminates breakage during wiping maintenance & transportation.
Also it provides natural air cooling for UV lamp, enhancing it's efficiency & life.
* Protective metallic enclosures provided at both ends of the sterilizing chamber for additional safety.
* Additional metallic base frame provided for the sterilizing chamber which facilitates easy wall fixing.
* Separate elegant control panel, equipped with hour count meter is provided which gives accurate reading of UV lamp life & enables it's timely replacement

UV WATER STERILIZERS are in-line units, uniquely designed & precision manufactured according to latest technology, very simple & convenient to operate, quick to install & requiring almost nil maintenance & operation care.
Available in various Models with capacities of 100, 500, 1500, 3000, 5000, 7000, 10000, 12000, 15000, 18000, 21000, 24000, 30000 Liters Per Hour.
UV Water Sterilizer is a simplest & most practical device for destroying instantly, harmful & disease causing micro-organisms like bacteria, viruses, yeasts, molds & algae etc. without use of heat or harsh chemicals & without imparting any foreign taste, odor, or corrosive allergenic properties to water to the finished products.
This is a far superior method of disinfections than conventional one of chlorination.

UV Disinfection Systems Application

1. Food processing and industrial water disinfection

2. Hospitals, various laboratory water disinfection, and high levels of pathogenic water disinfection

3. Municipal water

4. Biochemical pharmaceutical, cosmetics production water disinfection

5. Aquatic products processing water disinfection

6. Swimming pool water disinfection

7. Seawater, freshwater aquaculture breeding water disinfection

8. Ultra-pure water for electronic industry, and so on
