Высококачественные металлические кабельные ЖЕЛЕЗЫ ATEX Ex e tb с повышенной безопасностью для небронированных кабелей PG метрические NPT G-резьба по лучшей
- Категория: >>>
- Поставщик: Zhejiang,Hjsi,Connector,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-16-2025 | 1.47 $* | 1.12 $* |
| Jul-16-2025 | 1.81 $* | 1.7 $* |
| Jun-16-2025 | 1.31 $* | 1.13 $* |
| May-16-2025 | 1.67 $* | 1.10 $* |
| Apr-16-2025 | 1.53 $* | 1.64 $* |
| Mar-16-2025 | 1.33 $* | 1.43 $* |
| Feb-16-2025 | 1.59 $* | 1.64 $* |
| Jan-16-2025 | 1.24 $* | 1.29 $* |
Характеристики
Product Description
TECHINICAL DATE | ||
Design Specification | EN 60529; IEC 62321; EN 55032 EN 61000 EN 55035; GB/T19001-2016/ISO9001:2015; EN 60079 | |
Cable Types | Unarmoured | |
Application | Indoor and Outdoor Use | |
Strain Relief | Version A acc. to EN 60529 | |
Thread Option | Metric, PG, NPT, G Standard | |
Ex-Certificate | ATEX | |
Safety Level | Ex e IIC/Ex tb IIIC | |
According to | EN 60079-0:2012+A11:2013 ; EN 60079-7:2015 ; EN 60079-31:2014 | |
Marking | II 2 G Ex eb IIC Gb II 2 D Ex tb IIIC Db IP66 | |
Areas of Utilisation | 1 & 2, 21 & 22 Zones | |
IP Class | IP66 | |
Gland Size | M8*1~M72*1.5(2), PG7~PG63, NPT1/4~NPT2 1/2, G1/4~G2 1/2 | |
Gland Material Option | Brass(Natural), Nickel Plated Brass, Stainless Steel | |
Clamping Insert | PA6 | |
Sealing/Gasket Option | Thermoset Rubber/Silicone | |
Colour | Metallic | |
Operating Temperature | If Thermoset Rubber: -40°C to +100°C | |
If Silicone: -60°C to +180°C | ||
Accessory | Complete With Locknut and Washer | |
Approvals | ATEX ISO9001 CE ROHS | |
Features | For indoors, outdoors, Group II, III, Zone 1, 2, 21 and 22 hazardous areas. For use with all types of unarmoured cable housed in rigid or flexible conduit. Harder outer seal grips the cable giving superior cable retention and IP rating. Factory fitted with a specially formulated elastomeric seal for Built-in Safety™, seals on the inner sheath of the cable. Precision manufactured from high quality stainless steel AISI304, 316/316L on request, available in brass (Marine Grade™ Electroless Nickel Plated). Complete with a thread sealing gasket and an end cap safety gauge for correct gland selection. | |
Note | Cable glands and accessories can be developed as per the drawings and specifications. CONATCT US | |
Related Products
Packing & Delivery
Packaging Details | 50 Pieces /Box | ||||
Port | Ningbo Port/Shanghai | ||||
Delivery Time | 100 Pieces:3-5days 1000 Pieces:7-10days 》1000 Pieces:Date of negotiation | ||||
Our Company
Yueqing City Hongjuesi Connector Manufacturing Co.Ltd.is a professional Manufacture of a variety of wire and cable connector production and processing.The main products are metal cables waterproof connectors ,nylon cable glands,Marine stuffing,hose fittings,explosion-proof fittings,hoses and so on ,The company Uses automatic production equipment,strong technical force,It has a professional Health Production and management.
The company is committed to quality,safety and reliability,the credibility of the first,-class full-service,in In the market for economic development,and innovation in business development in the technology Enhance the quality of service standards,develop a broader market and dedication Our customer service!
Our Certifications
Professional certification, more assured
Product inspection follows SGS, VDE and eu CE/ROHS standards
Our Service
Factory wholesale
Industry and Trade together,
completely production system
Quality guarantee
We provide SGS certification.
Do all kinds of fabric inspection.
After-sales service
"Quality is our culture" we are responsible for every order .
FAQ
Q1: Are you a factory or trading company?
A1: We have factories. Welcome to visit us!
Q2: May I buy samples from you?
A2: Yes! You are welcome to place sample order to test our superior quality and service
Q3: May I know the status of my order?
A3: Yes .The order information and photos at different production stage of your order will be sent to you and the information will be updated in time.
Q4:Basis Servicer?
A4:24 hours online & Quick response.Ensure the products can meet the quality standards. Quality inspecting.
Q5: Can you give us a favorable discount?
A5: Of course, a favorable discount will be offered if the quantity is sizable.
Q6: Where is your factory located?
A6: Our factory located in yueqing Zhejiang Province that is closed to Shanghai and Hangzhou.Welcome to visit us.
Contact To Us
If you want to know more about our store's products, please click the title link, go back to the home page, you can add to the collection oh
If you want to know more information about this product or other products,
please click the picture on the right and send me your requirement information
