Мини-Подъемный Кран 9 5 м с гусеничной конструкцией и грузоподъемностью

Цена:24 000,00 $ - 46 000,00 $*

Количество:

Products Description

Technical data:

Model			HXB 3.0
Crane capacity			3.0t x 1.3m
Max working radius			8.45m
Max lifting height			9.5m
Winch	Hook up speed	5.5m/min （4 falls）
Winch		Diameter and length of wire rope	φ8mmx50m
Telescopic system	Boom length	2.56-8.92m
		Telescoping speed	6.36m/25 seconds
		Boom type	5-section hydraulically box beam, telescoping boom
Derrick	Derricking angle/speed	0-75°/25 seconds
Slewing	Slewing angle	360° (continuous) 0.6rpm
Outrigger	Form of outrigger	First phase--automatic Second phase--manual
Outrigger		Max extend range	Distance between two outriggers 4.04m（width）x3.47m（length）
Traction system	Drive	Hydrostatic，stepless forward and reverse
		Travel speed	0-3km/h
		Gradeability	30%
		Track	Synthetic rubber
		Track ground length	1.4m
		Track ground pressure	36Kpa
		Track width	200mm
Engine	Choose diesel or gasoline	Diesel engine: Yanmar L100N6-METM 7.4kw tank capacity 5.4L Gasoline engine: Honda GX390 9kw Electric start tank capacity 6L
Dual power optional			Diesel + Electric motor Gasoline + Electric motor
Motor	Power	3KW
Motor		Voltage	380V/50Hz and optional for others
Remote control	Operation	Boom rotation, boom derricking, boom telescopic, hook up and down, emergency stop button (Outriggers and walking are optional)
Dimension	Folded	3000(l) x 800(w) x 1500(h) mm
Weight	Unladen	2000kg
Hydraulic tank capacity			38L
