Электростатические диссипативные Тип плитки анти-статическое ОУР виниловых напольных
- Категория: Антистатическое напольное покрытие >>>
- Поставщик: Shenzhen,Gemisky,Technology,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-18-2025 | 291.28 $* | 297.72 $* |
| Jul-18-2025 | 236.30 $* | 241.48 $* |
| Jun-18-2025 | 286.45 $* | 292.72 $* |
| May-18-2025 | 284.49 $* | 290.69 $* |
| Apr-18-2025 | 227.73 $* | 232.69 $* |
| Mar-18-2025 | 279.50 $* | 285.4 $* |
| Feb-18-2025 | 277.68 $* | 283.40 $* |
| Jan-18-2025 | 275.45 $* | 281.7 $* |
Характеристики
Product Description
![esd tiles.jpg]()
Introduction
Today's technological environments where static electricity is more than annoying nuisance of a simple shock.
The release of static electricity can damage or degrade sensitive of electronic components,
ignite flammable gases and cause involuntary personnel movement or equipment malfunction.
Technical parameters
| Product Name | ESD Vinyl Floor |
| Thickness | 2-3mm |
| Size(mm) | 600 x 600/ 610 x 610/ 900 x 900 |
| Type | Conductive or Antistatic |
Pls kindly click here to contact us for more info.
| Item | Standard | Index |
| Size | SJ/T11236-2001 ASTM F536-98 | 600*600mm |
| 610*610mm | ||
| 900*900mm | ||
| Thickness | SJ/T11236-2001 ASTM F386-11 | 2.0, 2.5, 3.0mm |
| Surface resistance | SJ/T11236-2001 EN 1081
| 10e4-10e6 ohm conductive |
| 10e6-10e9 ohm antistatic | ||
| Voltage | AATCC-134 SJ/T11236-2001 | 50 V and 100V |
| IVI<100V | ||
| Static Decay | GJB2605-1996 | ≤2sec |
| Federal Test Method 1018 Method 4046 | 0.01sec | |
| Abrasive resistance(1000r) | SJ/T11236-2001 | ≤0.020g/cm2 |
| ASTM D1044-13 | 2500 0.48 | |
| 5000 0.95 | ||
| Fire resistance | SJ/T11236-2001 ASTM E648:2009a | FV-0 Class 1 |
| Dimensional | ASTM F2199:2009 EN 434 | ≤0.25% |
| Slip resistance wet | DIN 51130 | R9 |
| Residual concavity | SJ/T11236-2001 | ≤0.15 |
| EN 433 | 0.03 | |
| Color fastness | ISO 105B 02 | ≤6 |
| Chemical resistance | EN ISO 26987:2012 | OK |
| Toxic Tesing | GB 18586-2001 EN 71-3 | OK |
| Tvoc After 28 days | ISO 16000-3 | 10μ g/m3 |
| Wheel pressure | EN 425 | no effect |
Pls kindly click here to contact us for more info.
Warranty
- The conductive or antistatic properties of all our products need to be tested quality before out of the factory.
- The sales representative can also provide technical guidance in the job site.
- Within one year of purchase, defects of product in the materials and technology won't be happened.
- Compliance with our regulations for the installation and maintenance,10years of service life can be guaranteed(except for human reasons and installation error).
- Above guarantee replace any other assurances, including,but not limited to,any quarantee implied in the business feasibility or special purposes.
Installation
Conductive tile and Static-Dissipative tile should be installed on sub floors that are leveled,smooth and free of cracks.
Residual humidity should be under 2.5% tested with the CM Dumb test.Tiles, adhesive and installalion site should
reach a temperature of at least 18℃ and 24 hours before installation.
And Paste the Tiles with qualified conductive glue below 10eh ohm for further details on installation methods.
Pls kindly click here to contact us for more info.
Care and maintenance
Clean floor by machine-scrubbing with a good neutral detergent. Lightly soiled floors can be washed mop but also
should be periodically machine-scrubbed. Severe soiling or black marking can be removed with a floorcleaning machine,
clean pad and other commercial solution. Clear water rinsing is necessary after any scrubbing operation to remove all
cleaner Floor maintenance should apply spray and arind-ina.
If necessary, can maintenance the surface of tile by conductive wax periodically.
Structure
Pls kindly click here to contact us for more info.
Service Field
Our products adhering to the concept of health,safety,eco-environmental, and continuously optimize and improve the
PVC floor formula, our products use new generation of plasticizer DOTP.
----Only our products in market don't contain benzene ring structure in plasticizer.(phthalate,harmful to human health)
----Only our plasticizer in market can meet the standard of kids toys and food.
TVOC is a general for volatile organic compounds,mainly come from artificial products combustion products of fuels
and releases(interior decoration materials,paints,furniture,floors,etc.).
Our PVC flooring is the top level of TVOC,toensure the optimal indoor air quality.
Pls kindly click here to contact us for more info.
Packaging & Shipping
Related Products
Customized Solutions
Company Information
Favorable Comments
Gemisky specialize in exporting and manufacturing of ESD/Cleanroom product.
Except supply high quality products, we also provide custom service, such as logo, size and model etc.
Electrostatic Dissipative Type Tile Anti-static ESD Vinyl Floor
