PLC контроля трансформатор сухого типа двухслойные высокое качество машина для обмотки

Описание и отзывы

Трекер стоимости

Характеристики



 PLC Control Dry Type Transformer Double Layers High Quality Foil Winding Machine BRJ1000-2 is used to wind coils made of copper or aluminum foil. This foil winding machine can handle one or two layers of conductor foil and one or two layers of insulation material (such as paper or similar). Bus bars are welded with TIG welding process. The automatic foil edge alignment will make sure that the coil edges are straight and smooth when winding. Programming of this machine is done by means of a touch screen user interface.





Main Components



1.Main frame

2.Winding unit

3.Foil decoiler

4.Insulation decoiler

5.End-fill strip feeder

6.Cleaning system

7.Cutting system

8.Foil deburring system

9.Edge alignment system

10.Automatic welding unit

11.Electronic control system

12.Pneumatic system



Technical Parameters



Typical standard specifications of BRJ1000-2 are shown below, these can be easily modified as requested.

Axial Length (foil width):	1,000mm
Finished Coil Shape:	oval, round and rectangular
Conductor Foil Material ID.:	500mm
Number of Conductor Decoiler:	2
Length of Conductor Decoiler:	1,050mm
Conductor Decoiler Shaft:	adjustable Dia. range 400-520mm
Max. Coil Weight:	2,000KG
Winding Power:	15KW
Winding Spindle:	80×80×1350 mm
Number of Insulation Decoiler:	2
Width of insulation material:	1,450mm
Insulation Decoiler shaft:	Expandable (pneumatic open/close action)
End-fill Strip Feeder:	8
User Interface:	10inch (254mm) touch screen industrial PC / access controller
Counting Turns Range:	0 - 9999.9
