Поделиться:


Цена:22 292,43 ₽*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Sep-16-2025 26527.57 $* 27853.41 $*
Aug-16-2025 26305.55 $* 27620.96 $*
Jul-16-2025 22069.63 $* 23172.19 $*
Jun-16-2025 25859.33 $* 27152.88 $*
May-16-2025 22515.68 $* 23641.93 $*
Apr-16-2025 25413.46 $* 26684.51 $*
Mar-16-2025 25190.0 $* 26450.11 $*
Feb-16-2025 24967.41 $* 26215.65 $*
Jan-16-2025 24744.35 $* 25981.84 $*

Характеристики

Battery supplied Liquid handheld ultrasonic flow meter


RS485 Portable Liquid Handheld Ultrasonic Flow Meter

Application:

The ultrasonic flow meter is designed to measure the fluid velocity of liquid within closed conduit. The transducers are a non-contacting, clamp-on type, which will provide benefits of non- fouling operation and easy installation.

Features:

0.5% of linearity 0.2% of repeatability
Bilingual interface in Chinese and English 4-way flows totalizers
Transmission and receipt patents of balanced lower-voltage and multi-pulse Built-in date totalizers
Built-in data logger Good anti-interference performace
0.5 second totalizing period 100 Pico-second resolution of time difference measurement





Linearity 0.5%
Repeatability 0.2%
Accuracy ±1% of reading at rates>0.2mps
Response 0-999 seconds
Velocity ±32m/s
Pipe Size 15mm-6000mm
Rate Units Meter,Feet,Cubic Meter,Liter,Cubic Feet,USA Gallon,UK Gallon,
Oil Barrel,USA Liquid Barrel, UK Liquid Barrel;
Totalizer 7-digit totalizers for net accumulation and positive and negative accumulations
Liquid Types all liquids
Security Locks of Set values, you have to unlock while changing data;
Display 4x8 Chinese or 4x16 English letters
Communication Interface RS-232C,baud-rate :from 75 to 57600.Protocol made by the
manufacturer and compatible with that of the FUJI ultrasonic flow meter.
Transducers Model M1 for standard,other 3 models for optional
Transducer Cord Standard 2x5 meters,optional 2x10 meters
Power Supply 3AAA Ni-Hbuilt-inbatteries.When fully rech arged it will lastover 10 hours of operation.
100V-240VAC for the charger
Data Logger Built-in data logger can store over 2000 lines of data
Manual 7-digit press-key-to-gototalizer for calibration
Housing ABS

V-method Installation

V-method installation is the moswidely used mode for daily measurement with pipe inner diameters ranging from 15 millimeter to 200 millimeter. It is also called reflective mode or method.

Z-method Installation

Z-method is commonly used when the pipe diameter is between 300 millimeters and 500 millimeters.

W-method Installation

W-method is usually used on plastic pipes with a diameter from 15 millimeters to 100 millimeters
