Best Price 17 22 30 32 42 43 50 55 60 65 75 84 100 Inch multi touch film touch screen film capacitive touch foil
Product Description
Features & advantage:
1.Stable quality,9 years life time. 2.Zero pressure and precise touch,fast response. 3. Optional size:from 17" to 100" 4.Water-proof, Ultraviolet-proof, Vandal resistant,easy clean. 5.Suitable for different environment of indoor and outdoor. 6.Flexible,could be used in innovative design and special construction . 7.Fashionable and beautiful appearance,frameless,transparent, ultrathin design. 8.The same technology of projected capacitive touch as IPAD,maximum supports 100 points now . 9.Work through galss maximum thickness of 12mm .
Specification:
Available size
17"-100inch
Touch points
≤10 points
Series
ME-Mini
Touch deviation
≤0.5mm
The number of sensors
TX70 RX142(≤55inch)
TX80 RX142(>55inch)
Scanning speed
10ms /frame
Energy consumption
2W
Drive Type
Drive Free
Arm Reject
Yes
Custom
not support custom
Point report Rate
>100
Film thickness
≤100um
Light transmission rate
Above 93%
Supply voltage
5V USB
Transmission
USB2.0
Warranty
1 Year
Program-level
Kernel-level low-level drive
Technical certification
CE,ilac-MRA,CNAS,CAL,CMA
Ambient temperature
-20℃ to +70℃
Ambient lightness
Whole angle of the anti-glare
Touch support
Click, drag, zoom, rotate
Sensing distance
≤20mm(glass thickness )
Calibration mode
Software calibration
Program type
Andriod,Linux,Mac,Windows7/8/8.1/10(see note)
Transmission distance
≤50m ( plus USB signal amplifier, etc )
Safety distance
2mm( refers to the distance between the LCD screen and the film)
Packing List
1 * touch film circuit/ control board * 1 /USB cable * 1
