Машина для фильтрации воска тип соскабливания автоматический фильтр

AFE Filter is a new type of self-cleaning strainer independently developed by Shanghai JCI company with our own intellectual property. It is designed for continuous online filtration to remove impurities on the outer surface of filter screen via highly-efficient mechanical scrapping.

AFE Filter is mainly designed for high-viscosity and soft impurities filtration, with the precision range being 50-1,500μm. Featuring precise filtration can effectively remove impurities from the surface of filtering screens, thus removing more impurities with high efficiency. It applies to the filtration of water and various viscous liquids. AFE Filter designed and manufactured as per Shanghai JCI's standards for high performance, high quality and high reliability, it features internationally first-class quality.

Traditional filters easily get blocked when used to filtrating viscous materials and soft impurities. For this reason, large-sized filters are usually selected or manual cleaning is frequently conducted, resulting in heavy investment, heavy work and serious waste of materials. Such problems can be easily solved by AFE Filter with advanced self-cleaning mode. It can regularly maintain cleanness of filtering screens and expel waste fluid containing high-concentration impurities, thus reducing waste of materials. It has evident advantages and higher efficiency in filtrating poor-quality water and viscous materials such as adhesive, resin, polymer, coatings and grease. AFE Filter with notable technical advantages and low operation costs, it has gradually displaced the traditional manual filters in various fields, such as vibrating screeners, bag filters, basket filters, etc.

Product Details Show

How Does It Work?

Technical Parameters & Specifications

Technical features and advantages

1. Horizontal rotary scraping, scraping off the impurities directly, is good at filtering viscous liquids and removal of viscous, soft and suspended impurities;
2. Simple structure, easy dismounting; after removing the scraper, easy to take out the filter screen, and easy to clean the inside;
3. Automatic operation, continuous online filtration, to end up the heavy filter screen replacement and cleaning work;
4. Do not produce disposable filter material, saving consumables costs and environmental costs;
5. Small filtration pressure loss, stable flow rate, energy saving is beneficial to the continuous stability of the whole process;
6. Sealed filtration, preventing dangerous material leakage, is advantageous to the safe production and the staff health;
7. Discharge waste liquid with high impurities concentration can be recycled, to reduce the loss of high-value materials;
8. A variety of advanced control systems are optional, powerful, efficient and reliable;
9. Selection of world-renowned brands of components, high reliability, low costs.

Automatic Cleaning Control System

Part of Applicable Industries

Applicable fluid types: Water, cooling liquid, edible oil, paint, resin, adhesive, ink, pigment, polymer, kerosene, citric acid, fermentation broth, protein, soap, sorbitol, wet-end additive, rubber, ethanol, chocolate, candy, high-temperature oil, fruit juice and diesel, etc.

Filtration effect: Constant-value screening, removing large particles, purifying fluid, and protecting key equipment.

Filtration type: Mechanical online scraping filtration.
