Waste plastic crusher machine
low power-- high capacity

Product description

PC/SWP series crusher is mainly used for the waste PVC, PE pipe crushing, it can also be used for PET bottle, PE/PP film and other plastic lumps crushing.

Crusher Machine Main Features:

1. Plastic pipes specialized crusher;

2. Blade can be sharpened;

3. Easy operation for pipe input, superior cutting action



Crusher Machine Applications:

1. Various plastic pipes crushing;

2. Soft, hard and formed plastics profiles;

3. WPC profiles recycling


technical parameter:

PC series:

Model	mouth of feeding	capacity	motor power	fixed knife QTY	revovlving knife QTY
PC300	230*300	200-250KG/h	5.5KW	2	9
PC400	245*400	300-400KG/h	7.5KW	2	12
PC500	300*500	400-800kg/h	11KW	2	15
PC600	335*600	450-900KG/H	15KW	4	18
PC800	500*800	550-1100KG/H	22KW	4	24
PC1000	5000*1000	650-1300KG/H	37KW	4	30
PC1000B	600*1000	700-1500KG/H	55KW	4	6(big size)

SWP series.

Model	SWP200	SWP320	SWP360	SWP400	SWP630
Diameter of rotating blade	200	320	380	400	630
Rotating blade quantity	3	6 pcs/2sets	12 pcs/4sets	5	9 pcs/2sets
Rotating speed of blade (r/min)	870	650	650	500	480
Fixed blade quantity	2	2	2	2	2
Aperture of screen (mm)	8	10	10	10	12
Grinding capacity (Kg/h)	50-110	250-350	200-400	350-450	700-850
Power (kw)	4	11	22	13.2	45
Aperture of feed inlet (mm)	240*350	500*280	268*620	375*320	820*610
Machine weight (kg)	300	1400	1600	980	5000
