Automatic industrial Door Operator With CE

Specialized is engaged in the industrial door operator  research and development, manufacturing and sales, the company has 22 years experience in design and manufacture of electric door machine industry technical team and management team.Companycooperate withGerman companies, in strict accordance with the European standards for production, quality validation from users all over the world.

Type	BRD-Z1	BRD-Z2	BRD-Z3	BRD-Z4
Supply voltage	220v 50Hz	220v 50Hz	220v 50Hz	220v 50Hz
Motor power	450W	550W	450W	750W
Thermal protective	130℃	130℃	130℃	130℃
Working temperature	-20℃+50℃	-20℃+50℃	-20℃+50℃	-20℃+50℃
Shaft bore diameter	6m	6m	6m	6m
Ouput torque	50N.m	75N.m	50N.m	100N.m
Drift mandrel	25.4m	25.4m	31.8m	31.8m
Ouput speed	23r/min	23r/min	23r/min	23r/min
Net weight	12kg	12kg	12kg	12kg

The industrial door opener is mainly used in the industrial sectional door equipped with balance spring,remote control,wall control, but also can applied in lifting industrial door.

1. The operator is composed of motor, gearbox, manual release mechanism and control system.

2. Using high efficiency worm reducer, large speed ratio, high efficiency, low power, safety and good

    self-locking.

3. The operator is oil submerging ,good lubrication, low noise, long use life.

4. The built-in control system with remote control, manual control, limiting accurate, convenient adjustment.

5.The motor with thermal protection and overload automatic shutdown protection function.

6. Nice design, beautiful appearance, compact structure, small volume.

7.The suitable working environment temperature is between -20 ℃~ 50 ℃, IP54 protection class with stable pe

   rformance and safety.

8. Some customized special specifications for customer request.

The industrial door motors always applicate in warehouse, factory,commercial door, logistic, airport and so on.

BRDECO Group, established in 1995 and covering more than 30 million M2 area, is a modern enterprise specialized in full system of garage door motor, industrial door opener,steel building, such as steel structure, PU sandwich panel, thermal insulation and decorative panel, steel truss deck, and light steel villa.

BRDECO also has a strong productivity. We have more than 500 existing staffs. We have introduced several Italian fully automatic production lines and Chinese total productive management system. The annual output includes 1.2 sets of door motors, and 10 million tons of steel structure.
