Performance parameter

Sensor

640×480 CMOS

light source

Background light source: White LED     Positioning light source: Red LED

Reading accuracy

≥4mil

Scanning angle

Roll 360°, Pitch ± 55°, Skew ± 55°

Field of view

Level34°, ertical26°

Reading code system

2D

QR Code, Data Matrix, PDF417,Aztec, Maxi code, Chinese Sensible Code, EAN,UPC,Code 39,Code 93,Code 128,UCC/EAN 128, Codabar, Interleaved 2 of 5, ISBN,ISSN, MSI-Plessey,TF-6,ITF-14

1D

GS1 Data bar, GS1 Composite Code,Code11,

Industrial 25,Standard 25,Plessey,Matrix 2 of 5

Host size(L*W*H)

155mm*65mm*95mm

Package Size(L*W*H)

200mm*130mm*105mm

Shell material

ABS+PC

LED indication

Red, Blue

System interface

USB, Virtual serial port

Wireless parameter

Wireless working frequency band

433MHz ISM Frequency band

Transmission distance

100M(Open Space)With storage

Environmental parameters

Seismic resistance

100times/1M(wooden floor)

Operating temperature

-10℃-50℃

humidity

5%-95% (non-condensing)

Ambient brightness

0-100.000LUX

Power parameter

power supply

Built-in 3.7V 2000mAh lithium battery

Charging time

3-4hours

Working current

180mA

Working power

0.6W 170mA/3.7V

Typical Depth of Field

Bar code density4mil Code39

6.67mil PDF417

10mil Data Matrix

13milEAN-13

20milQR Code

Scan depth of field

40-90mm

30-130mm

50-90mm

50-200mm

25-240mm
