Характеристики

Electromagnetic flowmeter is a new type of flowmeter developed rapidly with the development of electronic technology from 1950s to 1960s. Electromagnetic flowmeter is an instrument which uses electromagnetic induction principle to measure the flow of conductive fluid according to the electromotive force induced by conductive fluid passing through an external magnetic field.

Product Description :

YEZON Electroplating and corrosion prevention mud integrated pipe type electromagnetic flowmeter PL111, the sensor and the converter. It is based on Faraday's law of electromagnetic induction. It is used to measure the volume flow of conductive liquid whose conductivity is greater than 5 μs/cm. It is an inductive instrument to measure the volume flow of conductive medium. Besides measuring the general conductive medium, it can also measure strong acids, strong alkali, mud glue and other special liquids. It is widely used in petrochemical, papermaking, environmental protection, food and municipal water conservancy testing and other fields.

Product Features:

A. measurement is not affected by changes in fluid density, viscosity, temperature, pressure and conductivity.
B. There are no blocking parts in the measuring pipe, no pressure loss, low requirements for straight pipe section, and unique adaptability for slurry measurement.
C. reasonable choice of electrode and lining materials, that is, good corrosion resistance and wear resistance.
D. digital processing has strong interference ability, reliable measurement and high accuracy.
E. ultra low EMI switching power supply, suitable for a wide range of power supply voltage, good anti EMI performance.
F. uses 16 bit embedded microprocessor, and its operation speed is fast and precision is high.
G. adopts SMD and surface mount (SMT) technology, and the circuit has high reliability.
H. can be equipped with RS485, RS232, HART, MODBUS PROFIBUS-DP and other digital signal output.
I. high definition backlight LCD display, easy to use, simple operation, easy to learn and understand.
J. Hourly Total Recording Function, Recording the Total Flow in Hours, Used for Time-sharing Measurement Values (Customized Selection)
There are three accumulators in K., which can show the positive cumulant reverse accumulation and difference accumulation respectively. The internal power failure clock can record the 16 power down time. (custom selection)
L. infrared handheld operator, 115KHz communication frequency, remote non-contact operation converter all functions. (custom selection)

Product Application :

Product Parameter:

Standard of execution	15-2000mm
Velocity range	0.1-15m/s
Precision grade	0.5%,1%
conductivity	≥5uS/cm,Actual conductivity≥30uS/cm
Nominal pressure	0.6MPA	1.0MPA	1.6MPA	2.5MPA
	DN1200-DN2000	DN300-DN1000	DN65-DN250	DN10-DN50
medium temperature	Chloroprene lining	Fluorosilicone rubber	PTFE lining	F46,PFA lining
	-20~+60° C	-20~+180° C	-30~+120° C	-20~+200° C
ambient temperature	-25~+60° C
Output signal	4-20mA(Load resistance0~750Ohm);Pulse / frequency, control voltage
Communication output	RS485,MODBUS ,HART,Profibus-DP,GPRS
Power supply	220VAC(±15%)OR 24VDC
Seal grade	IP65,IP67,IP68
Connection mode	Flange, thread, clamp
Relative humidity	5%~95%
Total power consumption	Less than 20W

Product drawing :(mm)

Working condition flow range table: (m /h)

Commonly used lining materials:

Liner Material	Name	Symbol	Performance	Top job Temperature	Applicable Liquid	Applicable Caliber
rubber	Chloroprene rubber	CR	Medium wear resistance, general resistance Corrosion of low concentration acid base salt	<60℃	Tap water and industrial water seawater	DN50~2000
	Polyurethane rubber	PU	Excellent wear resistance and resistance. Poor acid base properties	<60℃	Pulp, pulp and other slurry	DN25~500
	Fluorosilicone rubber	FV/MQ	Good wear resistance and high pull. Breaking force, high temperature resistance, no corrosion resistance.	<200℃	High temperature water	DN25~1200
Fluoroplastics	Teflon	F4(PTFE)	Chemically stable and resistant to boiling. Corrosion of hydrochloric acid, sulfuric acid and aqua regia	<120℃	Corrosive acid base salt liquid	DN10~1600
	Perfluoroethylene propylene (Teflon FEP)	F46(FEP)	Chemical properties are equivalent to F4 resistance. Pressure and tensile strength are better than F4	<60℃	Corrosive acid base salt liquid	DN10~400
	Tetrafluoroethylene and perfluorocarbons Copolymer of vinyl ether	PFA	Good wear resistance and high pull. Breaking force, high temperature resistance, no corrosion resistance.	<60℃	Corrosive acid base salt liquid	DN10~400

Common electrode materials:

one electromagnetic flowmeter microflow electromagnetic flowmeter

Material Science	Corrosion resistance
316	Application: 1. domestic sewage, industrial water, raw water, well water, urban sewage 2. weakly corrosive acid-base salt solution
Hastelloy B	Application: 1. non oxidizing acid such as hydrochloric acid (concentration less than 10%). 2. sodium hydroxide (concentration less than 50%), sodium hydroxide solution of all concentrations. 3. phosphoric acid, organic acid Not applicable: sulfuric acid
Hastelloy C	Application: 1. mixed acid and mixed acid and sulfuric acid solution 2. oxidizing salts and Fe+++, Cu++ and seawater 3. phosphoric acid, organic acid Not applicable: hydrochloric acid
Titanium(Ti)	Application: 1. salt, such as (1) chloride (chloride / magnesium / aluminum / calcium / ammonium / iron, etc.) (2) sodium salt, potassium salt, ammonium salt, secondary aluminate and seawater. 2. concentration is less than 50% potassium hydroxide, ammonium hydroxide and barium hydroxide solution. Not applicable: hydrochloric acid, sulfuric acid, phosphoric acid, hydrofluoric acid and other reducing acids.
Tantalum(Ta)	Application: 1. hydrochloric acid (concentration less than 40%), dilute sulfuric acid and concentrated sulfuric acid (excluding fuming sulfuric acid). 2. chlorine dioxide, ferric chloride, hypochlorite, sodium chloride, acetic acid and so on. 3. nitric acid (including nitric acid) and other oxidizing acids, the temperature below 80 degrees of aqua regia. Not applicable: alkali, hydrofluoric acid
Platinum(Pt)	Application: most of the acid, alkali and salt solution (including fuming sulfuric acid, fuming nitric acid) Not applicable: aqua regia and ammonium salt.
Tungsten carbide	Application: pulp, sewage, solid particle interference. Not applicable: inorganic acids, organic acids, oxides
