QY25K-II 4-секционный стрелы 25 т Гидравлический автокран

Цена:103 830,00 $ - 105 000,00 $*

Количество:

QY25K-II 4-Section Boom 25t Hydraulic Truck Crane Price

Main parameters:

Max. rated total lifting capacity: 25T

Fully extended boom:39.2M

Fully extended boom+jib:47.2M

Main configuration:

* SHANGCHAI engine, SC8DK280Q3WD615.329(206/213kw)

* Wire rope

* Hirschmann PAT

*Heater

Dimension	Unit	QY25K5-I
Overall length	mm	12300
Overall width	mm	2500
Overall height	mm	3290/3380
Weight
Total weight in travel	kg	31750
Front axle load	kg	6550
Rear axle load	kg	25200
Power
Engine model		SC8DK280Q3WD615.329
Engine rated power	kW/(r/min)	206/2200 213/2200
Engine rated torque	N.m/(r/min)	1112/1400 1160/1100-1600
Travel
Max. travel speed	km/h	75/80
Min. turning diameter	mm	21500
Min. ground clearance	mm	272
Approach angle	°	16/13
Departure angle	°	13
Max. grade ability	%	30/40
Fuel consumption for 100km	L	39
Main performance
Max. rated total lifting capacity	t	25
Min. rated working radius	m	3
Turning radius at turntable tail	mm	3065
Max. lifting torque	KN.m	961
Base boom	m	10.5
Fully extended boom	m	39.2
Fully extended boom+jib	m	47.2
