Машина для экстракции соснового масла пыльцы Сверхкритическая машина CO2

Product Application

Introduction of pine pollen oil Extraction machine Supercritical CO2 fluid Extraction machine

* This system is multi-function SCFE equipment, the working mode is intermittent or continuous way to extract solvent from solid or liquid material, the additive can be add to the supercritical fluid;
* The system has one extractor and two separators
* The highest working pressure of solid extractor is 50Mpa, the highest working temperature is 85°C;
* The design of pressure vessels according the related national standard and rule demand and with over pressure protection system which means enough safety valve;
* The whole equipment beauty, safety and easy operation, pressure temperature flow number can be showed from pressure meter and digital instrument. The material of pipe parts, valves, pipe lines, are all stainless steel(0Cr18Ni9Ti).

pine pollen oil Extraction machine Supercritical CO2 fluid Extraction machine

Main Features

pine pollen oil Extraction machine Supercritical CO2 fluid Extraction machine

Machine Parts of pine pollen oil Extraction machine Supercritical CO2 fluid Extraction machine

Name: CO2 high- pressure pump

Brand: Eternalwin

Original: China

Max working Pressure: 50MPa, pumps head with
cooling system

pine pollen oil Extraction machine Supercritical CO2 fluid Extraction machine

Name: extraction tank
Brand: Eternalwin
Original: China

Equipped with jacket water circling heating system, temperature adjustable, equipped with material barrel for both liquid and solid material.

Machine Parts pine pollen oil Extraction machine Supercritical CO2 fluid Extraction machine

Name: cooling system
Brand: Eternalwin
Original: China
Temperature range: -5℃~+5℃ (meet process
requirement)

pine pollen oil Extraction machine Supercritical CO2 fluid Extraction machine

1.What does Eternal Win need from me to quote a price?

a).Raw material
b).Production capacity per batch,we supply 0.5L~200L machine for you,big capacity of machine can be customized according to your request for your request.

2.What material can you process with this machine?
Our CO2 extract machine is widely used in extracting hemp oil, wheat embryo oil,fish oil,tobacco essential oil,Arteannuin,Sundrops oil,Gingerol,Pepper haematochrome,Hops extract, Agarwood oil etc.

3.What is the machine material you use?
Stainless steel.

4.What is the highest pressure does your machine can suffer?
50Mpa.Our standard design is 40Mpa.

5.Does the CO2 can be reused?
YES. CO2 can be used in circulation.

6.Does you machine can work under the conditions of supercritical and subcritical?
No,it can only work at supercritical state.

7.Can we do extraction test before purchasing?
Of course,we can do extraction test with your raw material and send you videos and pictures
for your reference.

8.Do you have machine in stock?
No,every machine is customized according to your order.

9.How long does it take to produce the machine once I place my order ?
The Supercritical CO2 extract machine' process flow is complex.Generally it takes about 60 workdays to Produce.We are responsible for the quality of machine our customers.Every procedure and details has to be inspected strictly.

10.How will my order be packed, can you provide the installation service?
Plywood case. And we will assemble and test the machine before packing.
Installation:We will send English manual after your purchase. If customer need, we will send one engineer for assembling and training for workers. USD100 per person per day, food, accommodation and air-ticket will be on clients.

pine pollen oil Extraction machine Supercritical CO2 fluid Extraction machine
