Цена:1 461,00 $*

Количество:



Описание и отзывы


Трекер стоимости

Месяц Минимальная цена Макс. стоимость
Aug-19-2025 1855.4 $* 1892.2 $*
Jul-19-2025 1505.11 $* 1535.91 $*
Jun-19-2025 1826.86 $* 1863.52 $*
May-19-2025 1812.23 $* 1848.66 $*
Apr-19-2025 1446.9 $* 1475.56 $*
Mar-19-2025 1782.96 $* 1818.49 $*
Feb-19-2025 1768.74 $* 1803.84 $*
Jan-19-2025 1753.80 $* 1788.49 $*

Характеристики


Product Description

5000 liters 2.5ton lpg gas tank                    click here


Application of 2.5ton lpg gas tank

2.5ton lpg gas tank is stored in a tank in a liquid state under appropriate pressure and is often used as a cooking fuel.At the same time,it is also used as a light vehicle fuel and so on.

\t
Product Name
\t
2.5ton lpg gas tank
\t
Model Number
\t
LPG-150/1.77/15
\t
Pressure Vessel Class
\t
2
\t
Working Medium
\t
Liquefied Petroleum Gas
\t
Full Capacity
\t
5cbm
\t
Working Pressure
\t
1.77MPA
\t
Working Temperature
\t
from -15 degree to 40 degree
\t
Product Size
\t
DN1220*1650*4794
\t
Net Weight
\t
2230KG
\t
Vessel Material
\t
Q345R


Technical parameters for 2.5ton lpg gas tank                       get offer


\t
Volume(m³)
\t
design pressure(MPa)
\t
Cylinder size(Dia.*length*thickness)mm
\t
Dimensions( Dia.* height * length)mm
\t
Material
\t
Net weight(Kg)
\t
5
\t
1.77
\t
\t
Φ1216*2010*5000
\t
Q345R
\t
1000
\t
10
\t
1.77
\t
DN1600*4400*10
\t
Φ1620*2400*5300
\t
Q345R
\t
2800
\t
15
\t
1.77
\t
DN1800*5250*12
\t
Φ1824*2600*6300
\t
Q345R
\t
4250
\t
20
\t
1.77
\t
\t
Φ2200*4500*12
\t
Q345R
\t
5200
\t
25
\t
1.77
\t
DN2200*5800*12
\t
Φ2224*3000*7100
\t
Q345R
\t
5850
\t
30
\t
1.77
\t
DN2200*7100*12
\t
Φ2224*3000*8400
\t
Q345R
\t
6800
\t
45
\t
1.77
\t
DN2600*7500*14
\t
Φ2628*3400*9000
\t
Q345R
\t
9770
\t
50
\t
1.77
\t
DN2600*8500*14
\t
Φ2628*3400*10000
\t
Q345R
\t
10800

The designed tank's diameter is about 1.5 meters.The length of the tank body is 7.5 meters, adding the head is 8.4 meters. Volume is 14.7 cubic meters. It can hold 8.6-8.8 tons of liquefied gas.


Making process of 2.5ton lpg gas tank                                 get offer

Related products
Certifications

Our certificate includes ISO9001, China special equipment manufacturing license (Class I pressure vessel, Class II low, medium pressure vessel, High pressure vessel, Class III low medium pressure vessel), radiation Safety license, Utility Model Patent Certificate, etc.

Our Company

Henan Jian Shen Metal Materials Co., Ltd. was founded in 2000, located in the birthplace of Oracle Bone Inscriptions hometown of the World Cultural Heritage Yin ruins. The company is located in Bei Meng Industrial Park North 107 National Road Ku River. The company covers an area of more than 50000 square meters, with a building area of more than 17500 square meters, has high and intermediate gas equipment pressure vessel professional engineering and technical personnel, set R & D, manufacturing, installation, trade roll into one. The company has established a sound quality assurance system, the whole process of technical supervision and inspection, product quality reliable.

Our Service

Pre-Sales Service

* Inquiry and consulting support.

* Sample testing support.

* View our Factory.

After-Sales Service

* Training how to instal the machine, training how to use the machine.

* Engineers available to service machinery overseas.

Packing & Delivery

2.5ton lpg gas tank is nude or plastic film pakaging.

Customers visit

Many foreign customers come to visit our factory, India, Germany, Iran, Nigeria, Japan, Korea, Turkey and so on, and give our company great praise.

Why choose us

Our biggest advantages:
1. Quality: We guarantee the quality of our products, if you bought our products, whenever you have any question about our products, please tell us, we will never cause products trouble for any customers.
2. Delivery time:We will delivery within 30 days after receive payment
3. After-sales service: Whenever our customers have question, after we received your question, we will give you feedback within 24 hours.
4. Price: We are the direct manufacturer with most competitive price, can help you save much money.
