30HP big power industrial air cooled water chiller


The injection molding chiller is commonly used in plastic processing,injection molding and modules cooling.The main function of this machine is to improve smoothness and reduce surface marks,shrinks or deformation of plastics wares,which can accelerate the process of plastic forming and improve molding efficiency highly.


injection chiller (1).jpginjection chiller (4).jpg


30HP big power industrial air cooled water chiller



Product Description


Features of 30HP big power industrial air cooled water chiller:


1.  Superior compressors from famous brands(Panasonic,Darkin,Sanyo,Copeland),high efficient shell condensers and evaporators with excellent cooling effect but low electric consumption.


2.  Equipped with precise electric temperature controller which is easy for operation and is capable of precisely controlling the water temperature from 7°c to 35°c.


3.  Stainless steel water tank avoid s rust and can be easily maintained or cleaned.


4.  Current-overload protector, high-and-low pressure switches, electronic time delayer,fault display system.Four main security systems to ensure safe operation.


5.  Single, double or quadruple compressors combination available which is economic and efficient.


6.  Applicable for cooling field in modern industry without influence from environmental temperature as the necessary equipment.



injection chiller (3).jpginjection chiller (6).jpginjection chiller (7).jpgTechnical specifications of 30HP big power industrial air cooled water chiller:
























































































































































































































































Model



TC-


3AC



TC-


5AC



TC-


6AC



TC-


8AC



TC-


10AC



TC-


12AC



TC-


15AC



TC-


20AC



TC-


25AC



TC-


30AC



TC-


40AC



TC-


50AC









Cooling capacity












50Hz



Btu/h



28541



36427



48820



66095



70977



94636



121181



189272



228704



252363



378544



457408



kw



8.36



10.6



14.3



19.3



20.8



27.7



36.9



55.5



66.9



74.9



110.9



133.9



Kcal/h



7188



9175



12296



16647



17876



23835



31780



47670



57601



63560



95340



115202



USRT



2.5



3.0



4.0



5.5



6.0



7.9



10.5



15.8



19.0



21.0



31.0



38.0



Voltage



380V-415V/3PHASE/50HZ



Compressor power



Kw



2.5



3.58



4.56



5.85



7.38



8.2



11.84



7.38x2



8.85x2



11.84x2



15.02x2



18.8x2



Refrigerant



R22



Fan power



Kw



0.35



0.2X2



0.25X2



0.35X2



0.45X2



0.5X2



0.8X2



0.5X4



0.5X4



0.45X6



0.5X8



0.8X8



Tank capacity



L



50



55



75



145



210



210



360



510



510



510



600



780



Freezing


waterflow



m³/h



1.44



1.84



2.46



3.33



3.58



4.77



6.37



9.55



11.54



12.73



19.10



23.08



Pipe size



mm



25



25



32



32



32



40



40



50



65



65



80



80



Pump power



HP



0.5



0.5



0.75



1



1



1



1.5



2



3



3



5



5



Weight



kg



150



175



260



320



380



410



710



830



1200



1400



1520



1620






Dimension


(mm)



Length



1000



1200



1258



1380



1500



1680



1800



1960



2450



2538



2998



3250



Width



600



580



560



800



900



810



995



1050



1150



1155



1158



1600



Height



1180



1180



1280



1400



1500



1400



1650



1935



1985



1980



1988



2250



30HP big power industrial air cooled water chiller





Our Services


1. Engineers are available to provide technically machinery services overseas.


2. All air-cooled chiller machines enjoy one-year warranty service.


3. 24 hours service both online and on telephone.


injection chiller (5).jpg


30HP big power industrial air cooled water chiller





Company Information


Thailand Tailong Plastic Mechanical Co., Ltd,whose headquarter is located in Thailand, has factories in dongguan and guangzhou in China.


We are a manufacturer of plastic machine with more than 20 years, can provide professional advice according to customer needs, and provide our customers with quality assurance of the machine.
Over the years, we have attended exhibitions around the world every year to keep abreast of the latest developments in the industry, so as to enrich our knowledge of machines and produce better machines
