Кварцевый кристалл из сплава с монитором высокой нагрузки и толщины
- Категория: Crystals >>>
- Поставщик: Zhengzhou,Tainuo,Film,Materials,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-20-2025 | 0.17 $* | 0.34 $* |
| Aug-20-2025 | 0.49 $* | 0.81 $* |
| Jul-20-2025 | 0.19 $* | 0.31 $* |
| Jun-20-2025 | 0.63 $* | 0.40 $* |
| May-20-2025 | 0.66 $* | 0.29 $* |
| Apr-20-2025 | 0.10 $* | 0.47 $* |
| Mar-20-2025 | 0.91 $* | 0.84 $* |
| Feb-20-2025 | 0.95 $* | 0.80 $* |
| Jan-20-2025 | 0.60 $* | 0.43 $* |
Характеристики
High Stress Deposition and Film Thickness Monitor Alloy Quartz Crystal
Product Description
Technical Parameters
Dimension | 14 mm Dia. |
Electrode Material | Alloy |
Sensor and Monitor | Thin film thickness monitor |
Life Time | Quartz crystals are consumable parts, no warranty of any kind |
Typical Applications | Designed for high-stress depositions, such as optical coating with dielectric materials and semiconductor processes with high-stress materials DC Sputtering RF Sputtering Thermal Evaporation Ion Plating Anticorrosive Coating |
Application Notes | Choose the quartz crystal with the right electrode material for your application - gold, silver, alloy: Recommend gold electrode crystals for most applications Silver electrode crystals work well for processes with high heat loads, such as sputtering Alloy electrode crystals are recommended for high-stress deposition, such as optical coating with dielectric materials and semiconductor processes with high-stress materials |
Notes | The recommended distance from source to sensor is 12 inch Avoid source splatter and heat load to the crystal. Additionally, please take notice of the bend radius dependent on the sensor that is ordered. |
Packaging & Shipping
Packaging: Plastic bag, opp bag or as your requirement.
Shipping and transportation as customer request. Generally, our mode of transport are by sea, by air or rail transport.
Our Services
1. Reply your inquiry in 24 working hours.
2. Experienced staffs answer all your questions in fluent English.
3. Customized design is available.
4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staff.
5. Professional factory : We are manufacturer, specializing in laboratory equipment.
Company Information
Zhengzhou TAINUO Film Materials Co., Ltd. is mainly engaged in the research and development, design, manufacturing and sales of equipment used in scientific researches. Our main products include: PVD magnetron sputtering coater, plasma sputtering coater, evaporating coater, spin coater, dip coater, tape casting coater, plasma cleaner, metallographic cutter, lapping and polishing machine, dental furnace, CVD tube furnace system, electrospinning system and so on.
Partial Company Products
Contact Information
Please do not hesitate to make an inquiry to us !
