Композитный манометр от
- Категория: Pressure Gauges >>>
- Поставщик: Kunshan,Alf,Machinery,And,Instruments,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Aug-18-2025 | 1.45 $* | 1.64 $* |
| Jul-18-2025 | 1.9 $* | 1.48 $* |
| Jun-18-2025 | 1.26 $* | 1.74 $* |
| May-18-2025 | 1.9 $* | 1.61 $* |
| Apr-18-2025 | 1.25 $* | 1.95 $* |
| Mar-18-2025 | 1.38 $* | 1.11 $* |
| Feb-18-2025 | 1.69 $* | 1.37 $* |
| Jan-18-2025 | 1.13 $* | 1.86 $* |
Характеристики
Detail Information
Range 15 to 15000 Psi Pressure Gauge Manufacturers Compound Pressure Gauge for Sale
| Model | PT004-1 NL |
| Description | No Lead Stainless Steel Case Dry Pressure Gauge |
| Application | For general use where the pressure medium is non-corrosive to brass,phosphor bronze, or beryllium copper |
| Size | 1.5"(40mm) 2"(50mm), 2.5"(63mm), 3.5"(95mm), 4" (100mm) and 6" (150mm) |
| Pressure Range | 15 to 15,000psi, vacuum, and compound |
| Socket | No lead brass lower mount or center back mount |
| Connection Thread | NPT, BSP, BSPT, PT, ZG, or other customized threads |
| Tube | Phosphor bronze, copper alloy |
| Case | Stainless steel |
| Bezel | Stainless steel press-on bezel |
| Window(Lens) | Acrylic, glass, and polycarbonate lens available |
| Dial plate | Single or dual scale (psi, kpa, mpa, bar, kg/cm2) |
| Accuracy | +/- 3/2/3% of full scale (ASME B40.1 Grade B) |
| Ambient Temperature | -40 to 60 ℃ |
| Certificate | CSA low lead listed |
Product Overviews
Production Flow
Application
Certification&Patent
ALF received the following certificates and patents:
- ISO9001:2015 manufacture of pressure gauge and door lock
- UL listing: use no oil pressure gauges
- CSA certificate: lead free pressure gauge
- ANSI Grade 3: entry door lock
- High-Tech Enterprise (Jiangsu Province)
- 32 different patents on products and processes
Our Company
Kunshan ALF Machinery & Instrument Co. Ltd. was founded in Shanghai in 1998. With a production base of 70,000 square meters located at Huaqiao Town, Kunshan, Jiangsu province, ALF is specialized in the production and export of pressure gauge and door lock.ALF look forwards to strengthen our cooperation with customers and suppliers and enter a fast-growth lane through training key personnel, fasten technical developments, improving product quality, and enhancing customer satisfaction.
Packing and shiping
