Product Description

Product Application


Self feeding concrete mixers are unique machines designed to batch,mix and transport concrete.The operate of the self feeding concrete mixers batches and introduces the ingredients required for mixing concrete into the drum using the loading bucket.The drum is usually reversible type,tilt type or a combination of both.


The 5th generation upgraded the bucket down function from the loading mixer to truly realize the multi-purpose loading function of the machine .At the same time, the brake caliper increased the braking performance and equipped with high-pressure car washing to keep the equipment clean,and increased the water tank to increase the output.


At this point,the 5th generation of products truly realizes the multi-purpose function of loading,stirring,transportation,car washing,etc.

Product Parameters
Machine size (mm)
5300*2350*2950
Wheelbase (mm)
2300
Total weight (kg)
7500
Engine
YuChai 4102 supercharged
Power (kw)
78 (105Hp)
Gearbox
265 separated type
Drive axle
2.0T wheel side deceleration bridge
Tires
16/70-R22.5
Bucket capacity (m³)
0.5
Drum power (m³)
3.2
Roller capacity
>=1.8
Reduction ratio
1:24
Rotating speed (RPM)
>=15
Gearbox
China brand
Tank capacity
Water: 1200L diesel: 110L Hydraulically
Loading qty
2 sets /40 HC
Concrete yield
10-12 m³/h
Warranty period
6 month

Advantage


1.Without operate attention , everybody could operate just like a loader.
2.24hours continue running without high temperature,without any stick for hydraulic system
3.High mixing effiency , 30s finished after loaded all materials
4.Container rotate controlled by signal , (soft limited & hard limited )together , to keep safety operation.
5.Container fitted degree same as Italy FIOIR brand ,ensure mixing fully and steady.
6.Auxiliary machinery could be supply , cement assient , water assient ,remote control assient.
7.Key part with international design , reducer , moter , hydraulic system and so on.

Detailed Images

Machine Parts

Name: Tire


Four wheel steering ,can be drive in complex pavement ,flexible and conveniet

Main Features

Name: SElf feeding system

Using the imported electronic balance from Italy.Can accurately control the meterial of ingredients.Sve

Our company

WEIFANG BEST POWER EQUIPMENT CO.,LTD

   Established in 1992, Weifang Best Power Equipment Co., Ltd. is a collectivized company integrating production, sales, and trade. Now we have five subordinate factories, a product development team including 30 professional researchers and 300 staff members. The production fields include construction machinery, power machinery and food machinery. The main products, like concrete mixer truck, gensets, and pumps, have been exported to Australia, the Middle East, Malaysia, Mongolia, Russia, etc. we have 7 dealers worldwide. With the tenet, "Credit First, Mutual Benefit and Common Development", Best power has become an excellent enterprise which is deeply trusted by customers.
Producing the top-class products.
Providing the top-class services.
Best power,
Do it best!

Packing & Delivery
Packaging
Size
5300*2350*2950mm
Weight
7500kg



Packaging Details
(Size: L*W*H). If export to Asian countries and near to Chian,the land transport way is better.We will use the tuck shipping to your country.
Packaging
Size
1220cm (L) * 240cm(W) *290cm (D)
Weight
22 T
Packaging Details
40 feet high cabinet, weight 22 tons, volume 68 cubic meters. The flat car is pulled to the port and loaded in containers.
FAQ


Q1.: Are you trading Company or Factory?
A: Our company is trade company,but we have our own factory,we have two factory,and we also work with other companies.

Q2: How about the quality of your products?
A: We have professional inspectors to control the quality of our products.Our key parts are imported by high quality parts manufacture from the world.And very glad to invite you to our factory.

Q3: Do you provide after-sale service?
A:Our product is guaranteed.The warranty period is 1 year.Our engineers will visit the site twice a year to guide the product functions.In addition, for exporting bulk products, we will strengthen quality control, extend the time of factory inspection, repeatedly inspect and pass several engineers' inspection and test in turn to ensure the reliability of the products.

Q4 : Do you provide equipment operation training?
A: Yes. Our engineers will visit the site twice a year to guide the product functions.In addition, for exporting bulk products.

Q5: How long is your delivery time
A: 5-7 days. If the order is large, may will extension of 5-10 days


Q6:  What is your acceptable payment terms.
 A: By T/T(30% in advance, 70% before delivery.)
