LT2230B хорошее качество дешевой 6pin водонепроницаемый 3-сторонний выход переключателя сброса
- Категория: Переключатели рычажные >>>
- Поставщик: Zhejiang,Lema,Electrics,Co.,Ltd.
Поделиться:
Описание и отзывы
Трекер стоимости
| Месяц | Минимальная цена | Макс. стоимость |
|---|---|---|
| Sep-19-2025 | 0.23 $* | 0.27 $* |
| Aug-19-2025 | 0.13 $* | 0.10 $* |
| Jul-19-2025 | 0.52 $* | 0.51 $* |
| Jun-19-2025 | 0.83 $* | 0.12 $* |
| May-19-2025 | 0.72 $* | 0.80 $* |
| Apr-19-2025 | 0.27 $* | 0.6 $* |
| Mar-19-2025 | 0.58 $* | 0.71 $* |
| Feb-19-2025 | 0.77 $* | 0.50 $* |
| Jan-19-2025 | 0.34 $* | 0.36 $* |
Характеристики
Product Description
Lema LT110B single pole on-off mini toggle switch 3a 250vac
 | ||
 | ||
| Brands | LEMA | |
| Model | LT2230B | |
| Voltage: | 250/125 VAC | |
| Electric current: | 15A | |
| Mounting Holes Dimension | φ12mm | |
| Contact form: | ON-OFF | |
| Package: | CARTON | |
| Size: | 29*52.5*16.2mm | |
| Material: | Bakelite | |
| Operating frequency | 30 times/min | |
| Initial insulation resistance | 100MΩmin.(at 500VDC) | |
| Initial contact resistance | 25MΩmax. | |
| Dielectric strength | Between non-consecutive terminals | 1,000Vrms, 50/60Hz for 1 min |
| Between non-current carrying metal parts and each terminal | 2,000Vrms, 50/60Hz for 1 min | |
| Between ground and each terminal | 2,000Vrms, 50/60Hz for 1 min | |
| Vibration resistance | 10-55Hz,1.5mm double amplitude | |
| Shock resistance | Durable: 1000m/s2(100G)max. Malfunction: 300m/s2(30G)max. | |
| Operating life | Mechanical life | 100,000 operations min. |
| Electrical life | 50,000 operations min. | |
About Us
Certifications
Transport
FAQ
 | |
| 1. How do you control the products’ quality? 100% Auto inspection machine and manual testing together before packing. |
2. What's your payment term? Samples cost can be paid by PayPal, Western Union. | |
| 3. Would you accept to use our logo? If you have good quantity, we can make OEM and ODM, customized specification. | |
| 4. Can I get a sample for reference? We are glad to send samples for your testing. Samples are free, but you may need to pay the express cost. | |
| 5. What is your delivery time? Usually it takes 15-20 working days for productions. | |
