Характеристики

Product Description

Multi Function digital ac voltmeter and ammeter

digital ac voltmeter and ammeter

Features:

1
Smart Size , high accuracy and stability.
2
Measure and display AC/DC voltage, current
3
Optional measuring range

Ordering Information:

Model
Power
Max digit
Normal range
DM3□-DV/DA□
DC 5V /12V/24V
3 1/2 digits
AA:2mA/20mA/200mA/2A/20A/200A
DM4C-DV/DA□
4 1/2 digits
AV:0.2V/2V/20V/200V/600V
DE3A-DA/DV□
AC/DC 10~30V
3 1/2 digits
DA:2mA/20mA/200mA/2A/20A/200A
DE3A-AA/AV
DV:0.2V/2V/20V/200V/600V(Special range need to oder)
Note: DM series only support DC range signal,DE series AC current range only support AC below 2A, larger than 2A need to be ordered.
Specifications:
Input
Refer to measured specifications table
Accuracy
3 1/2 digits:±0.5%F.S ±3Digit 4 1/2 digits:±0.2%F.S ±5Digit
A/D switch
Double integral
Sampling rate
About 2.5 times/second
Input impedance
Refer to measured specifications table
Display range
0~±1999,Decimal point switch through pin of PCB board.
Display
3 1/2 or 4 1/2 digits red 0.56 inch LED
Overflow indication
Display "1" or "-1"
Environment
0℃~50℃ 35~85%RH
Storage environment
20℃~60℃ 35~90%RH
Power supply
DE series:AC/DC 12~30V DM series: DC 5V
Power consumption
≤3W
Dielectric strength
AC 1500V 1min 50Hz
Insulation strength
100MΩ DC 500V
Dimension
Refer to mounting drawing
Vibration
Sweep-frequency vibration:10~50Hz
Weight
0.5kg
